onsemi Timer Circuit 1 Internal Timer 8-Pin SOIC Surface Mount MC1455DR2G

onsemi MC1455DR2G Timer Circuit is a high-stability semiconductor device incorporated in an 8-Pin SOIC surface mount package, designed for precise timing pulse generation in electronic circuits. This timer circuit employs the well-known 555 timer architecture, allowing monostable operation controlled by one external resistor and capacitor, or astable operation with accurate frequency and duty cycle control using two resistors and one capacitor.

Operating within a supply voltage range of 4.5V to 16V and an ambient temperature scope of 0°C to 75°C, the MC1455DR2G ensures reliable performance under standard industrial conditions. The compact 5 mm length and 1.5 mm height dimensions facilitate space-saving PCB designs with automated surface mounting.

It finds extensive application across various sectors including industrial electronics, automation, embedded processor systems, and other timing-based control systems. Compact SOIC package measuring 5 mm length and 1.5 mm height.

Operates within 4.5V to 16V supply voltage range. Features one internal timer based on the 555 timer architecture. Capable of both monostable and astable timer configurations. Surface mount installation suitable for automated PCB assembly.

Complies with RoHS environmental safety standards. Operating temperature range from 0°C to 75°C for reliable industrial use. Benefits from onsemi's established semiconductor quality and reliability.

This timer circuit is ideal for use in industrial automation, timing generation for control circuits, frequency generation, and various electronic applications that require precise timer control. Explore more Timer Circuits and semiconductor products to find the right components for your design on EnvMart.
