Samtec TSW Series Straight Through Hole Pin Header, 8 Contact, 2.54 mm Pitch, 1 Row, Unshrouded TSW-108-06-T-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-108-06-T-S |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Operating temp range | -55 °C to +125 °C with Gold -55 °C to +105 °C with Tin |
| Plating used | Au or Sn over 50 μ" (1.27 μm) Ni |
Key Features
- The housing material is black glass filled polyester ensuring durability and insulation.
- Contacts are made of phosphor bronze with gold plating for reliable conductivity.
- Single row, unshrouded design suits various PCB connector applications.
- Operates reliably from -55°C up to 125°C with gold plating.
- Termination type is solder, enabling secure joint connections.
- Compatible with industry-standard board-to-board connector systems.
- RoHS compliant design ensures environmental safety.
- Ideal for electronic components, power, and connector applications.
Product Description
Samtec TSW-108-06-T-S is a high-performance straight through hole pin header from the TSW series. Featuring 8 contacts spaced at a 2.54 mm pitch and housed in durable black glass filled polyester, this connector is engineered for reliable board-to-board connection in electronic assemblies. The male contacts are made from phosphor bronze and plated with gold to provide excellent conductivity and corrosion resistance.
This single row, unshrouded pin header supports through hole mounting and is suitable for a wide range of applications including industrial, electronics manufacturing, power connectors, and laboratory equipment. It operates safely at voltages up to 550V and temperature ranges from -55°C to 125°C when gold plated, ensuring performance under challenging conditions.
The termination type is solder, facilitating robust solder joint formation on printed circuit boards. The product is RoHS compliant, meeting environmental regulations for hazardous substances.
Black glass filled polyester housing for insulation and strength. Phosphor bronze contacts with gold plating for enhanced conductivity. Single row, 8 contact configuration with a 2.54 mm pitch. Supports through hole mounting and board-to-board connector systems.
Wide operating temperature range from -55°C to 125°C with gold plating. Voltage rating up to 550V for electrical safety. Solder termination for secure PCB connections. RoHS compliant to ensure environmental friendliness.
Ideal for electronics, industrial, and power connector applications.
Choose the Samtec TSW-108-06-T-S pin header for high reliability and quality in electronic component design. Explore more products in the PCB Pin Header category on EnvMart for comprehensive solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this pin header is 2.54 mm.
The maximum operating temperature for the TSW-108-06-T-S is 125°C when gold plated.
This pin header features 8 contacts.
The voltage rating for this model is up to 550V.
The housing is made of black glass filled polyester, while the contacts are made of phosphor bronze with gold plating.
This model uses solder termination for secure connections.
Yes, this pin header is RoHS compliant, ensuring it meets environmental regulations for hazardous substances.
The TSW-108-06-T-S supports through hole mounting.
The minimum operating temperature is -55°C.
This pin header has a straight orientation.
It is compatible with board-to-board connector systems.
The contacts in the TSW-108-06-T-S are male.
