Samtec TSW Series 36 Contact Unshrouded Straight Through Hole Pin Header, 2.54 mm Pitch, 1 Row TSW-136-08-G-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-136-08-G-S |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 36 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Contact System | .025" (0.635 mm) square post |
Key Features
- The connector features a single row of 36 gold-plated phosphor bronze contacts for superior conductivity.
- Housing is made from durable glass filled polyester ensuring mechanical strength.
- Designed for through-hole mounting with vertical straight orientation.
- Operates reliably within -55°C to 125°C temperature range.
- Rated for 550 V voltage providing robust electrical performance.
- The contact system uses 0.025 inch (0.635 mm) square posts for secure connections.
- Termination type is solder, suitable for PCB assembly.
- Unshrouded design allows easy mating and inspection.
Product Description
Samtec TSW-136-08-G-S is a high-quality, unshrouded straight through hole pin header designed with 36 contacts in a single row, featuring a pitch of 2.54 mm. The pin header uses gold-plated phosphor bronze contacts arranged in a vertical orientation and housed in robust glass filled polyester. This component is designed for through-hole solder termination, ensuring reliable mechanical and electrical connections for PCB applications.
Operating within a broad temperature range from -55°C to 125°C, the TSW Series supports voltages up to 550 V, suitable for demanding industrial, electronics, and communication system requirements. The 0.025 inch (0.635 mm) square post contact system enhances durability and secure mating cycles, making it ideal for applications requiring long-lasting connectors.
The unshrouded design provides ease of assembly along with clear visual inspection, facilitating maintenance and modifications. It is commonly used in electronic assemblies requiring board-to-board connection with high reliability and stable performance.
This product is part of Samtec's Extended Life Product™ range, known for extended durability including passing 10 year Mixed Flowing Gas (MFG) tests and achieving high mating cycles from 250 to 2,500.
The 36 contact configuration supports complex circuit interconnections. Gold plating on phosphor bronze contacts ensures excellent conductivity and corrosion resistance. Glass filled polyester housing offers strength and heat resistance.
Through-hole mounting permits stable mechanical attachment to PCB. Pin header is ideal for industrial automation, telecommunications, and electronic instrumentation. Explore more products from the PCB Pin Header category at EnvMart for reliable electronic component solutions.
