Samtec EHF Series Right Angle Through Hole PCB Header, 10 Contact(s), 1.27 mm Pitch, 2 Row, Shrouded EHF-105-01-L-D-RA
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 1.75A |
| Model | EHF-105-01-L-D-RA |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | EHF |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.29mm |
Key Features
- Constructed with phosphor bronze contacts plated with gold for durability and excellent conductivity.
- Housing made from liquid crystal polymer ensuring high mechanical strength and temperature resistance.
- Designed for through hole mounting with right angle orientation for PCB applications.
- Operates over a wide temperature range of -55°C to 125°C providing reliability in harsh conditions.
- Features ejector latches and a polarizing notch for secure and accurate mating with cables.
- Rated for 1.75 A current ensuring efficient power handling for various electronic devices.
- Tail pin length of 2.29 mm facilitating good solder connections on the PCB.
- Suitable for industrial and electronic assembly applications requiring wire-to-board connectivity.
Product Description
Samtec EHF-105-01-L-D-RA is a 1.27 mm pitch shrouded double-row right angle through hole PCB header designed for wire-to-board connector systems. It features 10 male contacts made of phosphor bronze with gold plating ensuring excellent electrical conductivity and corrosion resistance. The housing is constructed using liquid crystal polymer, offering high mechanical strength and thermal stability.
This PCB header supports a current rating of 1.75 A and operates reliably over a temperature range from -55°C to 125°C, making it suitable for demanding industrial, electronic assembly, manufacturing, and testing applications. The right angle orientation and through hole mount type facilitate straightforward PCB integration.
The EHF series includes a polarizing notch for accurate mating and ejector latches that enhance connection security. The contact tail pin length of 2.29 mm ensures good solder joint quality. These headers are ideal for applications requiring robust wire-to-board connections such as in communication equipment, instrumentation, and control systems.
Phosphor bronze contacts with gold plating provide durability and performance. Liquid crystal polymer housing offers heat resistance and strength. Right angle through hole mount design for easy PCB installation. Wide operating temperature range from -55°C to 125°C ensures reliability.
Ejector latch and polarizing notch enable secure, precise connector mating. Rated for 1.75 A current suitable for various electronic circuits. Tail pin length of 2.29 mm supports solder connection quality. Widely applicable in industrial, laboratory, manufacturing, and electronic systems.
No specific approvals but designed to high-quality standards.
This Samtec PCB header EHF-105-01-L-D-RA offers a reliable and versatile solution for PCB connectivity requirements. It is an excellent choice for professionals in electronics manufacturing, industrial automation, and laboratory instrumentation looking for durable connectors.
Explore further components and connectors in the Electronics & Electricals section on EnvMart to find compatible parts and accessories.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this PCB header is 1.27 mm.
This model features 10 male contacts.
The maximum operating temperature is 125°C.
The housing is made from liquid crystal polymer, which provides high mechanical strength and thermal stability.
It is rated for a current of 1.75 A.
This model is designed for through hole mounting.
The tail pin length is 2.29 mm, facilitating good solder connections on the PCB.
The orientation of the EHF-105-01-L-D-RA is right angle.
The minimum operating temperature is -55°C.
This PCB header supports a wire-to-board connector system.
The contacts are made of phosphor bronze and are plated with gold for excellent conductivity.
Yes, it features ejector latches and a polarizing notch for secure and accurate mating with cables.
