Littelfuse 1-Element Uni-Directional TVS Diode, Surface Mount DO-214 Package, 600 W Peak Pulse Power Dissipation P6SMB6.8A
Specifications
| Country of Origin | India |
|---|---|
| Brand | Littelfuse |
| Height | 2.237mm |
| Length | 4.57mm |
| Model | P6SMB6.8A |
| Width | 3.94mm |
| Mount Type | Surface |
| Series | P6SMB |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 10.5V |
| Diode Configuration | Single |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 6.45V |
| Maximum Reverse Stand-off Voltage Vwm | 5.8V |
| Peak Pulse Power Dissipation Pppm | 600W |
| Test Current It | 10mA |
| Maximum Peak Pulse Current Ippm | 58.1A |
| Maximum Reverse Leakage Current | 1mA |
Key Features
- Single diode configuration suitable for ESD protection.
- Surface mount DO-214 package with 2 pins for easy PCB mounting.
- Peak pulse power dissipation of 600 W for transient suppression.
- Minimum breakdown voltage of 6.45 V with maximum reverse stand-off voltage of 5.8 V.
- Clamping voltage of 10.5 V ensures effective voltage clamping during surge events.
- Operating temperature range from -65°C to 150°C supports harsh environments.
- Maximum peak pulse current of 58.1 A for robust transient handling.
- ESD protection compliant and automotive standards not applicable.
Product Description
Littelfuse P6SMB6.8A is a high-performance uni-directional transient voltage suppressor diode designed to protect electronic circuits from transient voltage spikes such as electrostatic discharge (ESD) and lightning surges. Packaged in a compact DO-214 surface mount package, this single-element component features robust voltage clamping and high pulse power handling of 600 watts.
The diode provides a minimum breakdown voltage of 6.45 volts with a maximum reverse stand-off voltage of 5.8 volts, ensuring prompt clamping of transient voltages to a safe level with a 10.5 volt maximum clamping voltage. It operates reliably across a wide temperature range from -65°C to 150°C, suitable for demanding industrial and electronic applications.
The device supports a maximum peak pulse current of 58.1 amps and demonstrates a low maximum reverse leakage current of 1 mA, which is critical for maintaining circuit integrity. Its surface mount package and 2-pin configuration enable easy integration onto printed circuit boards for protection of sensitive components.
This TVS diode is ideal for use in industrial automation, power supply protection, telecommunications, and electronics manufacturing to safeguard circuits against voltage transients and electrostatic discharge damage. Although it does not carry automotive certifications, it is suitable for a broad range of industrial and electronic environments.
Single element, uni-directional TVS diode configuration. Surface mount DO-214 package with 2 pins. 600 W peak pulse power dissipation capability. 6.45 V minimum breakdown voltage; 5.8 V max reverse stand-off voltage. 10.5 V clamping voltage with low leakage current.
Operating temperature from -65°C to 150°C. Maximum peak pulse current of 58.1 A. Compact dimensions: length 4.57 mm, width 3.94 mm, height 2.237 mm. This component can be used effectively in various electronic and electrical assemblies requiring transient voltage suppression to enhance circuit reliability and longevity.
Explore more on TVS Diodes and semiconductor protection solutions at EnvMart for industrial-grade electronic components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak pulse power dissipation of this model is 600 watts, allowing it to effectively handle transient voltage spikes.
The minimum breakdown voltage for the P6SMB6.8A is 6.45 volts, ensuring prompt clamping of transient voltages.
The maximum reverse stand-off voltage of the P6SMB6.8A is 5.8 volts, which helps to protect circuits from overvoltage conditions.
The clamping voltage for this model is 10.5 volts, which ensures effective voltage clamping during surge events.
The maximum peak pulse current for the P6SMB6.8A is 58.1 amps, allowing it to manage robust transient events.
This model operates reliably within a temperature range of -65°C to 150°C, making it suitable for harsh environments.
The P6SMB6.8A is packaged in a DO-214 surface mount package, which features a compact design for easy PCB integration.
This model has 2 pins, which facilitate straightforward mounting on printed circuit boards.
The maximum reverse leakage current for this diode is 1 mA, which is important for maintaining circuit integrity.
The diode configuration of this model is single and uni-directional, designed specifically for transient voltage suppression.
This transient voltage suppressor is suitable for applications in industrial automation, power supply protection, telecommunications, and electronics manufacturing.
The P6SMB6.8A is manufactured in India, contributing to its availability in various markets.
