Bourns Shielded Wirewound Surface Mount Inductor 120μH ±10% 1.65A Idc Ferrite Core 6mm Height 12.5mm Length SRR1260
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 6mm |
| Length | 12.5mm |
| Model | SRR1260 |
| Depth | 12.5mm |
| Packaging | Reel |
| Series | SRR1260 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 120μH |
| Standards/Approvals | RoHS |
| Package/Case | 1260 |
| Maximum DC Current | 1.65A |
| Maximum DC Resistance | 210mΩ |
| Inductance Tolerance | ±10 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 5.5MHz |
| Minimum Quality Factor | 26 |
| Inductor Construction | Wirewound |
Key Features
- The inductor features a ferrite core construction ensuring effective magnetic performance.
- Its compact size includes 6mm height and 12.5mm length, suitable for surface mount applications.
- The component provides a maximum DC resistance of 210mΩ and a maximum operating temperature of 125°C.
- The shielded design reduces electromagnetic interference enhancing reliability in circuits.
- RoHS compliant and comes in a reel packaging for easy automated assembly processes.
- Typical applications include DC/DC converters and power supplies for portable communication equipment, camcorders, LCD TVs, and car radios.
- Minimum quality factor of 26 ensures efficient inductance behavior at high frequencies up to 5.5MHz.
- Termination style is surface mount, molded construction with wirewound inductor construction.
Product Description
Bourns SRR1260 Shielded Wirewound Surface Mount Inductor, model SRR1260, delivers an inductance of 120μH with a tolerance of ±10% and supports a maximum DC current of 1.65A. It features a ferrite core optimized for low electromagnetic interference and high efficiency in compact electronic assemblies.
This surface mount inductor has a low profile with 6mm height and 12.5mm length dimensions, making it ideal for dense circuit board layouts. Its maximum DC resistance is 210mΩ with a maximum operating temperature rating of 125°C, ensuring performance stability under demanding conditions.
The shielded design effectively minimizes electromagnetic interference, suitable for applications in power supplies and DC/DC converters used in portable communication devices, camcorders, LCD TVs, and automotive radios. It exhibits a minimum quality factor of 26 and operates efficiently at self-resonant frequencies up to 5.5MHz.
This component complies with RoHS standards and is supplied on reels facilitating automated SMT assembly processes. The wirewound construction with molded termination ensures durability and reliable electrical characteristics.
The inductor features a ferrite core construction ensuring effective magnetic performance. Compact dimensions suitable for surface mount technology. Maximum DC current rating is 1.65A with ±10% inductance tolerance. Low DC resistance of 210mΩ enhances electrical efficiency.
RoHS compliant meeting environmental standards. Ideal for use in power supplies, DC/DC converters, and portable electronics. Shielded design reduces electromagnetic interference for signal integrity. Packaged on reel for manufacturing convenience.
This Bourns inductor is widely used in industrial, consumer electronics, telecommunications, and automotive sectors. EnvMart offers this reliable component to support high-performance PCB designs requiring compact and efficient power inductors. Browse our Electronics & Electricals category for additional Surface Mount Inductors and complementary passive components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Bourns SRR1260 inductor has an inductance value of 120μH with a tolerance of ±10%.
This model supports a maximum DC current of 1.65A.
The inductor has a height of 6mm and a length of 12.5mm, making it suitable for compact surface mount applications.
The maximum operating temperature for the Bourns SRR1260 is 125°C.
The inductor features a ferrite core construction, which ensures effective magnetic performance.
The maximum DC resistance of the Bourns SRR1260 is 210mΩ.
This inductor has a minimum quality factor of 26, ensuring efficient inductance behavior at high frequencies.
The maximum self-resonant frequency for this inductor is 5.5MHz.
The termination style of this inductor is surface mount with molded construction.
Yes, this inductor is RoHS compliant, meeting environmental standards.
The inductor is packaged on reels, facilitating automated SMT assembly processes.
Typical applications include DC/DC converters and power supplies for portable communication equipment, camcorders, LCD TVs, and car radios.
