Crydom Solid State Relay Panel Mount 100 A Load 48 V DC Load 32 V DC Control DC60D100

Crydom DC60D100 Solid State Relay is a high-quality panel mount device engineered for industrial and automation control systems. It supports a maximum load current of 100 A and a load voltage rating of 48 V DC with a control voltage range of 4 V DC to 32 V DC. The relay features an optically isolated MOSFET output and instantaneous switching function suitable for AC and DC control applications.

This relay includes screw-type terminals designed for secure connections and reliable operation in demanding environments. It has a compact form factor with dimensions 57.3 mm (L) x 22.6 mm (W) x 26.8 mm (H), enabling easy integration into control panels and electronic assemblies.

The device is designed to operate efficiently within a temperature range from -30°C up to 80°C. It has low on-state resistance of 15 ohms to minimize power loss and off-state leakage current of only 0.1 mA, making it highly efficient for industrial switching.

It conforms to international safety and environmental standards including RoHS, UL, and CE certifications, ensuring dependable quality and compliance.

This solid state relay features an LED indicator for status monitoring and can be paralleled for higher current applications when needed. It is an ideal component for automation, industrial machinery control, HVAC systems, and other electrical control applications requiring precise, reliable switching of DC loads.

Package contains the Crydom DC60D100 solid state relay with IP20 rating enclosure suitable for panel mount installations. It represents a robust and efficient solution for modern electrical and industrial automation systems.

Designed for panel mounting applications with robust screw terminals for secure connections. Supports maximum load current of 100 amperes and load voltage up to 48 volts DC. Optically isolated MOSFET output ensures high efficiency and low on-state resistance of 15 ohms.

Instantaneous switching function provides fast response for precise control. Laser status LED indicator assists in visual operation monitoring. Operates reliably within a temperature range of -30°C to 80°C for industrial conditions.

Complies with RoHS, UL, and CE standards for safety and environmental compliance. Compact dimensions of 57.3 mm length, 26.8 mm height and 22.6 mm width reduce panel space usage. Explore more Solid State Relay solutions and electrical components on EnvMart for your industrial and automation needs.
