TE Connectivity 2-Way 2 Contacts Shrouded Female IDC Connector, 4mm Pitch, Surface Mount 2106003-2

Name: TE Connectivity 2-Way 2 Contacts Shrouded Female IDC Connector, 4mm Pitch, Surface Mount 2106003-2
Brand: TE Connectivity
SKU: 103164
Price: 1.15 USD
Availability: InStock



Category IDC Connector Brand TE Connectivity Condition New

Specifications

Country of Origin	China
Voltage	250, 250V ac
Brand	TE Connectivity
Orientation	Right Angle
Current	8.5A
Mount Type	Surface
Housing Material	Thermoplastic
Contact Material	Copper
Series	SSL
Termination Type	IDC
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	4mm
Contact Plating	Tin over Nickel
Number of Contacts	2
Contact Gender	Female
Connector Gender	Female
Shrouded/Unshrouded	Shrouded

Key Features

Designed for termination of discrete wires onto LED printed circuit boards.
Supports 18 to 24 AWG stranded and solid wires.
Features dual IDC slots providing redundancy for secure connections.
Wire placement window allows visual inspection of correct positioning.
Tool-less termination enables easy and quick installation.
Rated for current of 8.5A and voltage of 250 V AC.
Operating temperature range is from -40°C to 105°C for versatile applications.
Contact plating is tin over nickel ensuring effective conductivity and corrosion resistance.

Product Description

TE Connectivity 2106003-2 2-Way IDC Connector Female is a shrouded, surface mount connector featuring 2 contacts with 4mm pitch, ideal for termination of discrete wires onto LED printed circuit boards and other applications requiring robust wire to board connections.

This connector supports a current rating of 8.5A and voltage rating of 250 V AC, suitable for solid state lighting and non-lighting industrial applications. It accommodates 18 to 24 AWG stranded and solid wires using dual IDC slots that provide redundancy and reliable electrical and mechanical connections.

The wire placement "viewing" window allows for visual confirmation of proper wire insertion, while tool-less termination facilitates rapid and efficient assembly processes. The contacts are plated with tin over nickel to offer corrosion resistance and high conductivity. The housing material is thermoplastic, providing durability and electrical insulation, with a right angle orientation and surface mount mounting type designed to optimize PCB space usage.

The connector is capable of operating within a temperature range of -40°C to 105°C, making it suitable for a variety of industrial, electronic manufacturing, and commercial applications requiring stable performance under varied environmental conditions.

TE Connectivity's SSL series IDC connector ensures secure wire termination, improving production efficiency and connection stability for electronics and lighting systems. The product is made in China and supplied as new.

Designed for termination of discrete wires onto LED printed circuit boards. Supports 18 to 24 AWG stranded and solid wires. Features dual IDC slots providing redundancy for secure connections. Wire placement window allows visual inspection of correct positioning.

Tool-less termination enables easy and quick installation. Rated for current of 8.5A and voltage of 250 V AC. Operating temperature range is from -40°C to 105°C for versatile applications. Contact plating is tin over nickel ensuring effective conductivity and corrosion resistance.

Housing made from thermoplastic provides durability and insulation. Right angle orientation and surface mount design suit compact PCB layouts. Explore more high-quality IDC Connectors and electronic components on EnvMart to suit your industrial, manufacturing, and electronics design needs.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This IDC connector is rated for a current of 8.5A and a voltage of 250 V AC, making it suitable for various applications including solid state lighting.

It supports 18 to 24 AWG stranded and solid wires, accommodating a range of wire types for secure connections.

The connector operates effectively within a temperature range of -40°C to 105°C, allowing for versatile applications in different environments.

This model features tool-less termination, which enables easy and quick installation, enhancing assembly efficiency.

The connector has a pitch of 4mm and features 2 contacts, designed for reliable wire-to-board connections.

The housing is made from thermoplastic, providing electrical insulation and durability for the connector's application.

This model is designed for surface mount, optimizing PCB space usage and facilitating compact layouts.

The contacts are plated with tin over nickel, ensuring effective conductivity and corrosion resistance.

Yes, it is specifically designed for the termination of discrete wires onto LED printed circuit boards, among other applications.

This connector features a right angle orientation, which is beneficial for space-constrained PCB layouts.

This IDC connector is manufactured in China, as indicated in the product specifications.

This connector is part of the SSL series by TE Connectivity, designed for robust wire-to-board connections.
