Roxburgh EMC RFI Filter 8A 480V AC 60Hz Flange Mount Stud Termination Single Phase IHF408
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Roxburgh EMC |
| Height | 55mm |
| Length | 230mm |
| Model | IHF408 |
| Depth | 147mm |
| Mount Type | Flange |
| Operating Frequency | 60Hz |
| Series | IHF |
| Maximum Operating Temperature | 85°C |
| Resistance | 15mΩ |
| Capacitance | 1μF |
| Minimum Operating Temperature | -25°C |
| Maximum Current | 8A |
| Number of Phases | 1 |
| Leakage Current | 600μA |
| Maximum Voltage | 480V ac |
| Inductance | 1.4mH |
| Standards/Approvals | EN 60939 |
| Termination Style | Stud |
| Power Loss | 1W |
Key Features
- Flange mount design with stud termination for secure installation.
- Operates at 60Hz frequency providing effective interference suppression.
- Features 1μF capacitance and 1.4mH inductance ensuring high performance.
- Leakage current is low at 600μA for minimal energy loss.
- Wide operating temperature range from -25°C to 85°C.
- Compact dimensions with length 230mm, depth 147mm, and height 55mm.
- Power loss limited to 1W ensuring energy efficiency.
- Complies with EN 60939 standard for EMI filtering.
Product Description
Roxburgh EMC IHF408 is a single phase RFI filter specifically designed for motor drive applications requiring an 8A maximum current and a voltage rating of 480V AC at 60Hz. The filter is constructed with a flange mount type and stud termination style, ensuring robust mechanical and electrical connections.
The filter includes a capacitance of 1μF and inductance of 1.4mH, providing enhanced suppression of radio frequency interference. Its leakage current of 600μA supports efficient energy usage while maintaining low interference emissions. The product operates safely within temperatures ranging from -25°C to 85°C.
Physically the filter has dimensions with a length of 230mm, depth of 147mm, and a compact height of 55mm. It exhibits a resistance of 15mΩ and power loss limited to 1W, ensuring minimal impact on system performance. This filter meets the EN 60939 standard, demonstrating compliance with industrial EMI filtering requirements.
Designed and manufactured in the United Kingdom, the IHF408 supports industrial and commercial motor applications that require reliable EMI filtration to comply with IEC950, VDE0871, EN55011 (industrial) and EN55022 (domestic) emission standards when properly installed.
Flange mounting design with stud termination ensures secure assembly. Provides robust RFI suppression for motor drive applications. Capacitance and inductance optimized for performance at 60Hz operation. Low leakage current minimizes energy loss and interference.
Wide temperature tolerance for versatile industrial use. Compact dimensions suit various installation environments. Low power dissipation for energy-efficient operation. Compliance with recognized European electromagnetic standards.
Manufactured to high quality standards in the United Kingdom.
This filter is ideal for use in industrial motor drives, manufacturing equipment, HVAC systems, and other electrical installations needing effective EMI mitigation. Ensure proper installation to achieve compliance with relevant emission standards and optimal performance.
Explore our range of Power Line Filters and EMI protection components at EnvMart for reliable solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The IHF408 filter has a maximum current rating of 8A.
It operates at a voltage of 480V AC and a frequency of 60Hz.
The filter has dimensions of 230mm in length, 147mm in depth, and 55mm in height.
The IHF408 features a stud termination style for secure installation.
It has a capacitance of 1μF and an inductance of 1.4mH, optimized for performance at 60Hz.
The leakage current is low at 600μA, which supports efficient energy usage.
The power loss is limited to 1W, ensuring energy efficiency.
It operates safely within a temperature range of -25°C to 85°C.
This filter complies with the EN 60939 standard for EMI filtering.
The resistance of this model is 15mΩ.
It uses a flange mount design for secure assembly.
It is suitable for industrial motor drives, manufacturing equipment, HVAC systems, and other electrical installations requiring effective EMI mitigation.
