Preci-Dip 811 Series Straight Surface Spring Loaded Connector, 2 Contacts, 2.54 mm Pitch, 1 Row 811-S1-002-30-014191
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 3.5A |
| Model | 811-S1-002-30-014191 |
| Mount Type | Surface |
| Housing Material | Fibreglass Reinforced Polyethylene Terephthalate |
| Contact Material | Brass |
| Series | 811 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
Key Features
- The connector operates at a voltage of 150V and current rating of 3.5A.
- The housing is made from fibreglass reinforced polyethylene terephthalate for durability.
- Features gold-plated brass contacts ensuring low resistance and excellent conductivity.
- The connector is shrouded for protection and has a straight contact orientation.
- Suitable for solder termination on surface mount pads.
- Operates reliably between -55°C to 125°C temperature range.
- Meets UL 94V-0 flammability standard ensuring safe, industrial grade use.
- Manufactured in Switzerland with high quality standards.
Product Description
Preci-Dip 811-S1-002-30-014191 is a straight surface spring loaded connector designed for PCB mounting with surface mount pads. It features 2.54 mm pitch and 2 gold-plated brass contacts arranged in a single row, shrouded to provide additional protection and stability in electrical connections.
This connector delivers a maximum current rating of 3.5A and withstands voltages up to 150V. The housing material is fibreglass reinforced polyethylene terephthalate, ensuring mechanical strength and high temperature resistance. It is rated to operate within a temperature range from -55°C to 125°C, making it suitable for demanding industrial and electronic applications.
The spring-loaded contact system provides low and stable electrical resistance with minimal risk of micro-discontinuities during mechanical vibration or motion, ensuring reliability and longevity. Its solder termination style suits modern surface mount PCB assembly processes.
Preci-Dip connectors are widely used in industrial controls, telecommunications, instrumentation, and other electronic manufacturing environments requiring compact, durable, and high-performance PCB connectors.
The connector operates at a voltage of 150V and current rating of 3.5A. The housing is made from fibreglass reinforced polyethylene terephthalate for durability. Features gold-plated brass contacts ensuring low resistance and excellent conductivity.
The connector is shrouded for protection and has a straight contact orientation. Suitable for solder termination on surface mount pads. Operates reliably between -55°C to 125°C temperature range. Meets UL 94V-0 flammability standard ensuring safe, industrial grade use.
Manufactured in Switzerland with high quality standards. Explore the wide range of PCB connectors available for electronics manufacturing and industrial applications at EnvMart.
Explore more products in our PCB Connectors & Wire Housings category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector has a voltage rating of 150V.
It has a current rating of 3.5A.
The connector features a pitch of 2.54 mm.
This model uses solder termination suitable for surface mount pads.
The housing is made from fibreglass reinforced polyethylene terephthalate, and the contacts are made of brass with gold plating.
It operates reliably within a temperature range of -55°C to 125°C.
The connector is shrouded, providing additional protection and stability.
This connector has 2 contacts arranged in a single row.
It is manufactured in Switzerland.
The contact orientation is straight.
It meets the UL 94V-0 flammability standard.
This model is widely used in industrial controls, telecommunications, and instrumentation applications.
