Semtech 6-Element Uni-Directional TVS Diode Array 300 W, 8-Pin SOIC SMDA05-6.TBT
Specifications
| Country of Origin | India |
|---|---|
| Brand | Semtech |
| Height | 1.5mm |
| Length | 4.9mm |
| Model | SMDA05-6.TBT |
| Width | 3.9mm |
| Mount Type | Surface |
| Series | SMDA05-6 |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -55°C |
| Pin Count | 8 |
| Number of Elements per Chip | 6 |
| Clamping Voltage VC | 11V |
| Diode Configuration | Complex Array |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 6V |
| Maximum Reverse Stand-off Voltage Vwm | 5V |
| Peak Pulse Power Dissipation Pppm | 300W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 17A |
| Maximum Reverse Leakage Current | 20μA |
Key Features
- Uni-directional diode array protects data I/O lines effectively.
- Peak pulse power dissipation of 300 W ensures robust transient protection.
- Comes with 6 elements per chip for comprehensive coverage.
- Supports ESD protection up to ±15kV (air) and ±8kV (contact).
- Surface mount SOIC package with 8 pins is compact and easy to integrate.
- Operating temperature range from -55°C to 125°C suits harsh environments.
- Minimum breakdown voltage of 6 V and maximum reverse stand-off voltage of 5 V.
- Maximum peak pulse current of 17 A provides high surge handling capability.
Product Description
Semtech SMDA05-6.TBT is a 6-element uni-directional TVS diode array designed for transient voltage suppression with a peak pulse power rating of 300 W. Packaged in a compact 8-pin SOIC surface mount format, this device is ideal for protecting sensitive electronic circuits and data lines from voltage spikes.
This diode array features a complex configuration with six elements per chip, ensuring high reliability and effective protection against electrostatic discharge (ESD) and other transient events. The device exhibits a minimum breakdown voltage of 6 V and a maximum reverse stand-off voltage of 5 V with a clamping voltage of 11 V, making it suitable for protecting circuits with these voltage thresholds.
The operating temperature range from -55°C to 125°C allows use in various industrial, commercial, and communications applications requiring durable and reliable transient voltage suppression. Its maximum peak pulse current rating of 17 A and low leakage current of 20 μA contribute to energy efficiency and surge robustness.
This product is well-suited for electronic equipment protection in industrial automation, telecommunications, computing, and other electronic assemblies. The compact 8-pin SOIC package facilitates high-density PCB layouts and easy surface mounting.
Uni-directional diode array protects data I/O lines effectively. Peak pulse power dissipation of 300 W ensures robust transient protection. Comes with 6 elements per chip for comprehensive coverage. Supports ESD protection up to ±15kV (air) and ±8kV (contact).
Surface mount SOIC package with 8 pins is compact and easy to integrate. Operating temperature range from -55°C to 125°C suits harsh environments. Minimum breakdown voltage of 6 V and maximum reverse stand-off voltage of 5 V.
Maximum peak pulse current of 17 A provides high surge handling capability. Low maximum reverse leakage current of 20 μA minimizes energy loss. Clamping voltage set at 11 V for efficient voltage regulation. Explore more TVS Diode Arrays and semiconductor components for enhanced electronic protection and performance at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak pulse power dissipation of this model is 300 W, ensuring robust transient protection for sensitive electronic circuits.
This unit operates within a temperature range of -55°C to 125°C, making it suitable for harsh environments.
The clamping voltage is set at 11 V, which helps in efficient voltage regulation during transient events.
This model features 6 elements per chip, providing comprehensive coverage for transient voltage suppression.
The maximum reverse stand-off voltage for the SMDA05-6.TBT is 5 V, suitable for protecting circuits operating at this voltage threshold.
The maximum peak pulse current rating of this diode array is 17 A, which contributes to its high surge handling capability.
It comes in a compact 8-pin SOIC surface mount package, facilitating high-density PCB layouts and easy integration.
The minimum breakdown voltage is 6 V, which is critical for its operation in transient voltage suppression applications.
The maximum reverse leakage current is 20 μA, which helps minimize energy loss during operation.
This diode array is well-suited for protecting electronic equipment in industrial automation, telecommunications, and computing applications.
The height of this model is 1.5 mm, which contributes to its compact design.
The width is 3.9 mm and the length is 4.9 mm, making it suitable for high-density PCB layouts.
