TE Connectivity Circular Connector 24 Contacts Panel Mount Socket Male Nylon Housing 600V CPC Series 796190-1
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 600.0V |
| Brand | TE Connectivity |
| Orientation | Straight |
| Model | 796190-1 |
| Mount Type | Panel Mount |
| Housing Material | Nylon |
| Series | CPC |
| Termination Type | Crimp |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -50°C |
| Standards/Approvals | RoHS |
| Pole Format | 24 |
| Number of Contacts | 24 |
| Contact Gender | Male |
| Shell Size | 23 |
| Mating Type | Keyed |
| Connector Size | Standard |
| Plug/Socket | Socket |
| Coding | A |
Key Features
- Constructed from UL 94V-0 black thermoplastic for durability.
- Designed for industrial applications with operation from -50°C to 125°C.
- Provides secure connection with keyed mating and AV coding.
- Supports a voltage rating of 600 volts ensuring safe electrical performance.
- Features 24 contacts arranged in a straight orientation for efficient wiring.
- Includes a bonded peripheral elastomer seal for environmental protection.
- Shell size 23 fits standard CPC series connectors.
- Meets RoHS compliance for hazardous substances.
Product Description
TE Connectivity 796190-1 Circular Connector is a high-quality industrial circular connector designed for panel mount applications. It has 24 straight contacts configured in a male socket style and is part of the CPC series with AV coding. The connector housing is made of UL 94V-0 black thermoplastic nylon, ensuring high durability, electrical insulation, and compliance with safety standards.
This connector supports a voltage rating of up to 600 volts and is suitable for demanding industrial, manufacturing, and electronic assembly environments where reliable connections are critical. It features crimp termination type contacts that provide secure mechanical and electrical connections.
Operating temperature ranges from -50°C to 125°C, making it suitable for various environmental conditions. The keyed mating design and flange mount type guarantee proper alignment and robust mechanical engagement, preventing incorrect connections.
The connector includes a bonded peripheral seal made from grey elastomer, providing environmental sealing against dust and moisture, necessary for industrial circular connector applications.
TE Connectivity's CPC Series 1 sealed single-piece circular connectors provide reliable performance in electronic components, industrial equipment, and automation systems. This connector is RoHS compliant, ensuring adherence to environmental regulations.
Constructed of UL 94V-0 black thermoplastic nylon housing for flame retardancy. 24 straight male socket contacts with keyed CPC series AV coding. Panel mount flange with sealing for harsh environments. 600 V voltage rating suitable for industrial applications.
Operating range from -50°C to 125°C for temperature resilience. Crimp termination type for secure electrical contact. RoHS compliant for restricted hazardous substance levels. Shell size 23 standard connector dimensions.
This product is suitable for electronics manufacturing, industrial automation, electrical panel assemblies, and commercial equipment requiring durable, sealed circular connectors. Explore more products in Industrial Circular Connectors on EnvMart to find compatible connectors and accessories that fit your project needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector supports a voltage rating of 600 volts, ensuring safe electrical performance in industrial applications.
It operates within a temperature range of -50°C to 125°C, making it suitable for various environmental conditions.
This model features 24 contacts arranged in a straight orientation for efficient wiring.
The housing is constructed from UL 94V-0 black thermoplastic nylon, providing durability and electrical insulation.
Yes, this connector meets RoHS compliance for hazardous substances, ensuring adherence to environmental regulations.
It uses crimp termination type contacts, which provide secure mechanical and electrical connections.
The shell size is 23, which fits standard CPC series connectors.
This model features a panel mount design, allowing for secure installation in various applications.
Yes, it includes a bonded peripheral elastomer seal that provides environmental protection against dust and moisture.
The connector has a keyed mating design, which ensures proper alignment and prevents incorrect connections.
The country of origin for this connector is India.
It is suitable for electronics manufacturing, industrial automation, electrical panel assemblies, and commercial equipment requiring durable, sealed connections.
