TE Connectivity DuraSeal Insulated Ring Terminal 5 mm Stud Size 12 AWG 10 AWG Wire Size Yellow 697233-000

TE Connectivity 697233-000 DuraSeal Insulated Ring Terminal features a heat-shrinkable nylon insulation that provides superior protection for electrical connections against environmental factors such as water, salt, mechanical abuse, vibration, and abrasion. Designed specifically for 5 mm stud sizes, it supports wire sizes ranging from 12 AWG to 10 AWG (3 mm² to 6 mm²), making it suitable for various electronic and automotive applications.

The contact is made of copper and plated with tin for excellent conductivity and corrosion resistance. The insulation material is nylon, enhancing durability and providing a secure seal after heat shrink activation. With an overall length of 39.98 mm and an outer ring diameter of 10 mm with an inner ring diameter of 5.3 mm, this terminal ensures snug fitting and reliable connections.

Operating in a wide temperature range from -55°C to 125°C, this product is durable in harsh and varying climates commonly encountered in automotive, marine, and industrial electrical wiring. The bright yellow color aids in identifying terminal sizes quickly during installation and maintenance.

DuraSeal terminals include a heat-shrinkable coating lined with hot-melt adhesive that adheres to the cable insulation upon heating, sealing out contaminants and increasing the mechanical strength of the joint. This makes the terminal highly resistant to wire pull-out and abrasion, extending the life of the connection.

Ideal for use in automotive builds approved by most car manufacturers, marine applications, and wherever environmental sealing and reliability are critical. These terminals provide long-lasting connection solutions suitable for professional and industrial electrical wiring work.

Durable nylon insulation with a heat-shrinkable tube provides mechanical protection and water resistance. Copper contact material with tin plating ensures reliable electrical conductivity. Supports wire sizes 12 AWG to 10 AWG (3 mm² to 6 mm²) for versatile electrical connections.

Bright yellow color coding aids in quick size identification. Operating temperature range from -55°C to 125°C suits harsh environments. Overall length of 39.98 mm with precise ring diameters for secure fit. Heat-shrink adhesive seals prevent moisture ingress and improve durability.

Approved for automotive and marine uses requiring environmental sealing.

This product is a specialized Ring Terminal for reliable electrical connections in demanding industrial, automotive, and marine settings. Explore more options in the Electronics Components category at EnvMart for related connectors and splices.
