Cosel DC/DC Converter 12V DC 2.5A, 13V Input, 4.5V Minimum Input, 30W PCB Mount MGFS40
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | Converters / DC-DC Converters Cosel MGFS40 DC/DC Converter, 12V dc/ 2 |
| Brand | Cosel |
| Efficiency | 87% |
| Length | 25.4mm |
| Model | MGFS40 |
| Depth | 9.9mm |
| Gross Weight | 30g |
| Width | 25.4mm |
| Mount Type | PCB |
| Series | MGFS40 |
| Package Type | 1 x 1 in |
| Minimum Operating Temperature | 85°C |
| Number of outputs | 1 |
| Ripple and Noise | 150mV |
| Maximum Output Power | 30W |
| Maximum Input Voltage | 13V dc |
| Standards/Approvals | CE, RoHS, cURus |
| Minimum Input Voltage | 4.5V |
| Output Voltage 1 | 12V dc |
| Output Current 1 | 2.5A |
| Isolation Voltage | 1.5kV dc |
| High reliability | not built-in Aluminium and tantalum electrolytic capacitor |
Key Features
- Wide input voltage range from 4.5V to 13V supports flexible DC input sources.
- High efficiency of 87% achieved via synchronized rectification technology.
- Compact 1 x 1 inch package size with 25.4mm length and width for tight PCB integration.
- Built-in overcurrent protection and I/O isolation voltage of 1.5kV DC ensure robust operation.
- Meets CE, RoHS, and cURus standards for safety and compliance.
- Low ripple and noise of 150mV delivers stable and clean DC output.
- Maximum operating temperature rated at 85°C for reliable performance.
- Output voltage adjustable by external variable resistor if required.
Product Description
Cosel MGFS40 DC/DC Converter, model MGFS40, provides a precise 12V DC output at 2.5A current, delivering a maximum power of 30W. Designed for PCB mounting, this converter supports a wide DC input voltage range from 4.5V minimum to 13V maximum, enabling flexible integration into various electronic systems.
The device features a compact footprint of 1 x 1 inch with dimensions of 25.4mm by 25.4mm and a depth of 9.9mm, making it suitable for space-constrained board designs. With a high efficiency of 87% facilitated by a synchronized rectification circuit, it assures energy-efficient power conversion, minimizing heat dissipation.
Safety and durability are enhanced through built-in overcurrent protection circuits that recover automatically and an isolation voltage rated at 1.5kV DC for 1 minute, suitable for industrial and commercial electronic applications. Ripple and noise are kept low at 150mV to protect sensitive components and ensure stable output voltage quality.
The product meets international compliance standards including CE, RoHS, and cURus certifications, underscoring its quality and environmental safety. It operates reliably within a temperature range encapsulating a maximum of 85°C, supporting robust operation in demanding environments.
Additional operational flexibility is provided by external adjustment of output voltage via a variable resistor and a built-in remote ON/OFF function. The converter avoids the use of aluminum and tantalum electrolytic capacitors to increase long-term reliability.
Manufactured in Japan, this MGFS40 series DC/DC Converter is ideal for industrial, electronic, laboratory, telecommunications, and power supply applications requiring efficient and reliable DC voltage conversion on PCBs.
Wide input range from 4.5V to 13V DC. Output voltage fixed at 12V DC with 2.5A maximum current. Compact 1 x 1 inch PCB mount package. High efficiency of 87% utilizing synchronized rectification. Built-in overcurrent protection and 1.5kV DC isolation.
Compliance with CE, RoHS, and cURus standards. 150mV max ripple and noise for clean output. Operating temperature up to 85°C. Manufactured in Japan for high reliability and quality. Explore more power supply and converter products at EnvMart for advanced electronic and industrial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The input voltage range for this model is from 4.5V to 13V DC.
This model provides a maximum output power of 30W.
It achieves an efficiency of 87% through synchronized rectification technology.
The dimensions are 25.4mm x 25.4mm x 9.9mm, making it suitable for compact PCB designs.
The output voltage is fixed at 12V DC with a maximum current of 2.5A.
Yes, it includes built-in overcurrent protection and an isolation voltage of 1.5kV DC.
The maximum operating temperature is rated at 85°C.
It meets CE, RoHS, and cURus standards for safety and compliance.
The maximum ripple and noise is specified at 150mV, ensuring stable output.
The output voltage can be adjusted externally using a variable resistor if required.
This converter is designed for PCB mounting.
It is manufactured in Japan, ensuring high reliability and quality.
