TRACOPOWER High Performance 15W DC/DC Converter Through Hole 12V/625mA, 36V dc Input THN 15-2422N
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters TRACOPOWER THN 15N DC/DC Converter, 12V dc/ 625 mA |
| Brand | TRACOPOWER |
| Efficiency | 90% |
| Length | 25.4mm |
| Model | THN 15-2422N |
| Depth | 9.9mm |
| Width | 25.4mm |
| Mount Type | Through Hole |
| Series | THN 15N |
| Maximum Operating Temperature | 70°C |
| Package Type | Encapsulated |
| Operating temp. range | - 40°C to +85°C |
| Minimum Operating Temperature | -40°C |
| MTBF | 1670000h |
| Number of outputs | 2 |
| Maximum Output Power | 15W |
| Maximum Input Voltage | 36V dc |
| Minimum Input Voltage | 18V |
| Output Voltage 1 | 12V dc |
| Output Current 1 | 625mA |
| Isolation Voltage | 1.6kV dc |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
| Output Voltage 2 | -12V dc |
| Smallest encapsulated 15W Converter! Ultra compact size | 1.0 x 1.0 x 0.4 |
Key Features
- It provides dual outputs with an isolation voltage of 1.6kV dc for reliable performance.
- The encapsulated metal package measures 25.4mm by 25.4mm with a depth of 9.9mm.
- It supports operation in extreme temperatures from -40°C to 70°C without derating.
- High efficiency up to 90% reduces power loss and heat generation.
- The device has a mean time between failures (MTBF) of 1,670,000 hours ensuring durability.
- It includes remote On/Off control and output voltage trim capability for flexibility.
- This converter is ideal for mobile equipment, instrumentation, communication, and industrial electronics where PCB space is critical.
Product Description
TRACOPOWER THN 15-2422N is a high performance 15 Watt DC/DC converter designed for robust industrial and electronic applications. It features an encapsulated shielded metal case sized 1 inch by 1 inch by 0.4 inch (25.4 x 25.4 x 9.9 mm) with through hole mounting for durable installation.
Capable of operating with an input voltage range of 18V to 36V dc, this converter produces two isolated output voltages, including a regulated 12V dc output with a 625 mA current rating. It achieves isolation voltage up to 1.6kV dc to ensure electrical safety and noise reduction in complex circuits.
The THN 15-2422N converter incorporates an EN 55032 class A filter and offers high efficiency of approximately 90%, minimizing no-load power consumption and improving energy use. Its exceptional MTBF of over 1.6 million hours guarantees reliable, long-term operation even in demanding environments ranging from -40°C to +70°C.
Additional features include remote On/Off switching and an output voltage trim range of ±10% allowing fine adjustment to suit specific application needs. The compact encapsulated design is ideal for systems where PCB space is limited, making it suitable for mobile equipment, instrumentation, communication devices, distributed power architectures, and industrial electronics.
Encapsulated shielded metal package with through hole mounting. Wide 2:1 input voltage range from 18V to 36V dc. Two isolated outputs with 12V dc output at 625mA current. 1.6kV dc electrical isolation for enhanced noise immunity.
High efficiency up to 90%, reducing heat dissipation. MTBF of 1,670,000 hours ensures exceptional reliability. Operating temperature range from -40°C to 70°C. Remote On/Off control and ±10% output voltage trim capability.
This product is manufactured in Taiwan, Province of China, and comes from a trusted range of high quality DC/DC converters. It is suitable for industrial, laboratory, communication, and instrumentation applications requiring compact, efficient, and reliable DC power conversion.
Browse EnvMart's Electronics & Electricals > Converters > DC/DC Converter category for more high-performance power supply solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates within an input voltage range of 18V to 36V dc.
It provides two isolated outputs: a regulated 12V dc output with a current rating of 625 mA and an additional -12V dc output.
The converter achieves high efficiency of approximately 90%, which helps to minimize power loss and heat generation.
The THN 15-2422N features an isolation voltage of 1.6kV dc, enhancing electrical safety and noise reduction.
It can operate in extreme temperatures from -40°C to +70°C without derating.
The encapsulated metal package measures 25.4mm by 25.4mm with a depth of 9.9mm.
Yes, it includes remote On/Off control for flexible operation.
The MTBF is rated at 1,670,000 hours, ensuring long-term reliability.
This model supports through hole mounting for durable installation.
It is ideal for mobile equipment, instrumentation, communication devices, and industrial electronics where PCB space is critical.
The input ratio is 2:1, allowing for flexibility in input voltage management.
This product is manufactured in Taiwan, Province of China.
