Schneider Electric TeSys K 3-Pole Reversing Contactor 48V AC Coil, 9A, 4kW, 3 NO Contacts, 690V AC LC2K0910E7
Specifications
| Country of Origin | India |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Reversing |
| Length | 58mm |
| Model | LC2K0910E7 |
| Depth | 57mm |
| Width | 90mm |
| Mount Type | DIN Rail |
| Series | TeSys K |
| Power Rating | 4kW |
| Maximum Operating Temperature | 50°C |
| Minimum Operating Temperature | -25°C |
| Terminal type | Screw |
| Number of Poles | 3 |
| Standards/Approvals | UL, RoHS, IEC, EAC, CSA, CCC |
| Contact Voltage | 690V ac |
| Coil Voltage | 48V ac |
| Normal State Configuration | 3 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 9A |
| Number of Auxiliary Contacts | 1 |
| Auxiliary Contact Configuration | 1 NO |
| Operational Current Ie | 9A |
| Control Circuit Voltage Uc | 48V ac |
| Contactor Application | Resistive Load, Motor Control |
| Pole and Throw Configuration | 3 |
| Ue Rated Voltage Power circuit | 690 V AC 50/60 Hz, Signalling circuit |
Key Features
- The contactor features a 3-pole configuration with 3 normally open (NO) contacts.
- Rated operational voltage of 690V AC with a contact current of 9A.
- Power rating of 4kW suitable for AC-4, AC-3, and AC-1 categories.
- Equipped with one auxiliary contact configured as 1 NO for control signaling.
- Mounts easily on DIN rails with screw type terminals for secure wiring.
- Operating temperature range from -25°C to 50°C ensuring durability in varied environments.
- Features a pre-assembled reversing power busbar for simplified installation.
- Complies with international standards including UL, RoHS, IEC, EAC, CSA, and CCC.
Product Description
Schneider Electric LC2K0910E7 TeSys K 3-Pole Reversing Contactor features a 48V AC coil and a rated operational voltage of 690V AC, 50/60 Hz.
Designed primarily for motor control and resistive load applications, this contactor supports AC-4, AC-3, and AC-1 categories, providing reliable performance across industrial and commercial environments.
This model includes three normally open power poles (3 NO) with a contact current rating of 9A and a power rating of 4kW. It also incorporates one auxiliary contact configured as 1 NO to facilitate control signaling tasks.
The contactor is designed for DIN rail mounting and uses screw terminals, enhancing installation flexibility and secure wiring connections. Its compact dimensions (90mm width, 58mm length, 57mm depth) help reduce panel space requirements.
Operational temperature ranges from -25°C to 50°C, making it suitable for a wide range of environmental conditions without degradation in performance. Manufactured to meet global quality and safety certifications including UL, RoHS, IEC, EAC, CSA, and CCC standards, ensuring compliance with industrial regulations.
It comes pre-assembled with a reversing power busbar, streamlining wiring for motor reversing applications. This product aligns with Schneider Electric’s commitment to sustainability under the Better World program, as it is designed for disassembly.
The contactor supports motor reversing functions and resistive load control. Rated coil voltage is 48V AC for control circuit compatibility. Includes one auxiliary contact for additional functionality in control circuits.
Meets multiple international standards for safety and environmental compliance. The compact size supports efficient use in control panels. Designed for easy installation on DIN rails with screw terminals. Operational temperature range supports diverse industrial applications.
Part of the TeSys K series known for durability and performance.
This Reversing Contactor is ideal for industries requiring precise motor control such as manufacturing, HVAC systems, and automation sectors. It provides reliable operation and help ensure system safety and efficiency.
Explore more Schneider Electric products and related contactors on EnvMart to support your industrial automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a power rating of 4kW, suitable for AC-4, AC-3, and AC-1 categories.
The rated operational voltage is 690V AC, compatible with both 50Hz and 60Hz power systems.
It features a 3-pole configuration with three normally open (NO) contacts.
The coil voltage for this model is 48V AC, suitable for control circuit applications.
It has a contact current rating of 9A, allowing it to handle various load types.
The dimensions are 90mm in width, 58mm in length, and 57mm in depth.
The operational temperature range is from -25°C to 50°C, making it suitable for diverse environments.
It is designed for DIN rail mounting and uses screw terminals for secure wiring connections.
Yes, it includes one auxiliary contact configured as 1 NO for control signaling tasks.
It complies with multiple international standards including UL, RoHS, IEC, EAC, CSA, and CCC.
It is designed for motor control and resistive load applications, suitable for industrial and commercial environments.
It comes with a pre-assembled reversing power busbar, simplifying installation for motor reversing applications.
