Samtec CES Series Straight Through Hole PCB Socket 50-Contact 1 Row 2.54 mm Pitch Solder CES-150-01-T-S

Name: Samtec CES Series Straight Through Hole PCB Socket 50-Contact 1 Row 2.54 mm Pitch Solder CES-150-01-T-S
Brand: Samtec
SKU: 99219
Price: 5.54 USD
Availability: InStock



Category PCB Socket Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	400V
Brand	Samtec
Orientation	Straight
Current	5.5A
Model	CES-150-01-T-S
Mount Type	Through Hole
Housing Material	Black Glass Filled Polyester
Contact Material	Bronze
Series	CES
Termination	Through-hole
Termination Type	Solder
Maximum Operating Temperature	105°C
Sub Type	Socket Strip
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2.54mm
Standards/Approvals	RoHS
Contact Plating	Tin
Number of Contacts	50
Connector System	Board-to-Board
Contact System	Dual Leaf

Key Features

The socket supports a maximum current of 5.5A for robust electrical performance.
It has a black glass filled polyester housing offering durability and heat resistance.
The contact system is dual leaf bronze plated with tin for reliable conductivity and corrosion resistance.
Designed with a straight orientation and board-to-board connector system for versatile circuit connections.
It is rated for operation between -55°C and 105°C, suitable for demanding environments.
The socket complies with RoHS standards, ensuring no harmful substances are used.
Mounting type is through-hole, providing secure mechanical and electrical connections in PCB assemblies.
The product supports a voltage rating of 400V for various electronic applications.

Product Description

The Samtec CES-150-01-T-S is a high-quality PCB socket featuring 50 contacts arranged in a single row with a 2.54 mm pitch. It is designed for through-hole mounting and solder termination, providing reliable and durable connections for electronic assemblies.

Constructed with a black glass filled polyester housing, this socket offers excellent mechanical strength and temperature resistance, capable of operating in environments ranging from -55°C to 105°C. The bronze dual leaf contact system plated with tin ensures consistent conductivity and corrosion protection over the product lifecycle.

This PCB Socket supports a maximum current of 5.5A and voltage rating up to 400V, making it suitable for various industrial, laboratory, manufacturing, and commercial electronic applications. Its straight orientation and board-to-board connector system add to its versatility for complex circuit designs.

RoHS compliance guarantees the product meets environmental regulations, making it safe for use in modern electronics manufacturing. The through-hole mount type secures the socket firmly to the printed circuit board, facilitating a sturdy and efficient assembly process.

The socket features 50 contact points in one row, providing compact and high-density PCB connection options. The housing is made from durable black glass filled polyester, enhancing thermal and mechanical properties. The bronze dual leaf contact system with tin plating delivers reliable electrical performance.

The product operates effectively in temperatures spanning from -55°C to 105°C. It supports a maximum current of 5.5A and voltage rating of 400V. Through-hole solder termination ensures solid mechanical and electrical connections.

Designed in the CES series to accommodate single and double row configurations up to 100 pins. Ideal for use in electronics manufacturing, repair, and prototyping environments. Compliant with RoHS to ensure environmental safety.
