Samtec ESQ Series Straight Through Hole Elevated PCB Socket 10-Contact 1 Row 2.54 mm Pitch Solder ESQ-110-14-G-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 225V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 23A |
| Model | ESQ-110-14-G-S |
| Mount Type | Through Hole |
| Special Features | Standard and low insertion force contacts with .025" (0.635 mm) square tails for PC/104™ applications |
| Housing Material | Black Glass Filled Polyester |
| Contact Material | Bronze |
| Series | ESQ |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Elevated Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Connector System | Board-to-Board |
| Contact System | Tiger Buy™ |
Key Features
- Elevated socket strip design for enhanced PCB connection.
- Supports a current rating of 23A for reliable power handling.
- Made with black glass filled polyester housing for durability.
- Gold-plated bronze contacts ensure excellent conductivity and corrosion resistance.
- Mount type is through hole with a straight orientation for easy installation.
- Operating voltage up to 225V supports various electronic applications.
- Wide operating temperature range of -55°C to 125°C for versatile environments.
- Tiger Buy™ contact system provides secure and efficient signal transfer.
Product Description
Samtec ESQ-110-14-G-S is a high-quality straight through hole PCB socket from the ESQ Series designed for electronic component board-to-board connections. Featuring 10 contacts in a single row with 2.54 mm pitch, it facilitates reliable solder termination in electronic assemblies.
The housing is constructed from black glass filled polyester, providing excellent mechanical strength and durability. Bronze contacts plated with gold ensure superior electrical conductivity and resistance to corrosion, supporting continuous current up to 23 amps. This socket is rated for a nominal voltage of 225 volts, making it suitable for various industrial and commercial electronic applications.
Its through hole mount type with a straight orientation enables robust mounting and ease of installation on PCBs. The product supports a broad operating temperature range from -55°C to 125°C, allowing use in demanding environments such as industrial, manufacturing, and laboratory electronics.
The Tiger Buy™ contact system incorporated in this socket enhances reliable signal integrity and connection stability. It is designed for use in single, double, and triple row configurations of up to 108 pins, with standard and low insertion force contacts featuring .025" (0.635 mm) square tails suited for PC/104™ compliant applications.
Elevated socket strip design for optimal PCB connection performance. High current capacity of up to 23A for power applications. Durable black glass filled polyester housing for long-term use. Gold-plated bronze contacts for enhanced conductivity and corrosion resistance.
Through hole mounting and straight orientation for easy PCB integration. Rated voltage of 225V supports a wide range of electronics. Wide temperature tolerance from -55°C to 125°C for versatile environments. Tiger Buy™ contact system ensures consistent connection quality.
Compatible with multi-row configurations up to 108 pins. Standard and low insertion force contact options available.
This PCB Socket is ideal for applications in industrial electronics, power and connectors assembly, electronic manufacturing, and laboratory equipment. It is a reliable component for ensuring secure and durable electrical connections on printed circuit boards.
Browse the Electronics & Electricals category on EnvMart to explore more PCB connectors and sockets like the Samtec ESQ-110-14-G-S, designed to meet diverse industrial and electronic assembly needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a continuous current rating of 23A, making it suitable for reliable power handling in various applications.
The maximum operating voltage for the ESQ-110-14-G-S is 225V, allowing it to be used in a wide range of electronic applications.
The housing is constructed from black glass filled polyester, which provides excellent mechanical strength and durability.
This model features 10 contacts in a single row with a 2.54 mm pitch, facilitating reliable solder termination.
It operates within a wide temperature range of -55°C to 125°C, making it suitable for demanding environments.
This socket uses a through hole mount type with a straight orientation, which simplifies installation on PCBs.
The contacts are plated with gold, which enhances electrical conductivity and provides resistance to corrosion.
It includes standard and low insertion force contacts with .025" (0.635 mm) square tails, suitable for PC/104™ applications.
This socket is part of the ESQ Series, designed for board-to-board connections in electronic assemblies.
Yes, this model is RoHS compliant, ensuring it meets environmental standards for hazardous substances.
It utilizes a board-to-board connector system, which is essential for connecting electronic components effectively.
Yes, it is designed for use in single, double, and triple row configurations of up to 108 pins.
