3 Valve Manifolds-Instrumentation Manifolds Orifice Size 157 in. (4.0 mm), 3M-302
Specifications
| Applications | Industrial |
|---|---|
| Working Temperature | PTFE packing from -65 Degree F to 450 Degree F (-54 Degree C to 232 Degree C) Graphite packing from -65 Degree F to 1200 Degree F(-54 Degree C to 649 Degree C) |
| Maximum Pressure | Stainless steel up to 6000 psig (413 bar) Alloy C-276 up to 6000 psig (413 bar) Alloy 400 up to 5000 psig (345 bar) |
| Orifice Size | 0.157 in. (4.0 mm) CV 0.35 |
Key Features
- Testing for every valve with nitrogen at the maximum working pressure
- Upper stem and lower stem design, Stem threads above packing protected from system media
Product Description
3 Valve Manifolds-Instrumentation Manifolds Orifice Size 157 in.(4.0 mm), 3M-302 are designed for differential pressure applications. 3-valve manifolds is composed of three interrelated three valves. According to the function of each valve in the system, it can be divided into: high pressure valve on the left, low pressure valve on the right, and balance valve in the middle. 3 valve manifolds is used with differential transmitter to connect or disconnect the positive and negative pressure measuring chamber from the pressure point, or to connect or disconnect the positive and negative pressure measuring chamber
- Safety back seating seals in fully open position
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The orifice size of this manifold is 0.157 in. (4.0 mm) with a flow coefficient (CV) of 0.35.
This model uses PTFE packing for temperatures from -65°F to 450°F (-54°C to 232°C) and graphite packing for temperatures from -65°F to 1200°F (-54°C to 649°C).
It is designed for industrial applications, particularly for differential pressure measurement.
The manifold consists of three interrelated valves: a high pressure valve on the left, a low pressure valve on the right, and a balance valve in the middle.
The working temperature range for the PTFE packing is from -65°F to 450°F (-54°C to 232°C).
The working temperature range for the graphite packing is from -65°F to 1200°F (-54°C to 649°C).
It includes safety back seating seals that are effective in the fully open position.
The balance valve is used to connect or disconnect the positive and negative pressure measuring chamber from the pressure point.
Yes, this manifold is specifically designed to be used with a differential transmitter for pressure measurement applications.
The manifold is available in stainless steel, Alloy C-276, and Alloy 400 materials.
