Nuvotem Talema 230 V ac, 115 V 2 x 55 V ac Toroidal Transformer 2 Output 225 VA 92431-P2S2

Nuvotem Talema 92431-P2S2 Toroidal Transformer is a high-quality electrical component designed for use in various industrial and electronic applications. It features a primary voltage of 230 V ac and 115 V, with two secondary outputs delivering 2 x 55 V ac at a secondary current of 2.05 A, and power capacity rated at 225 VA.

This transformer is engineered with an open toroid center and single primary winding, providing excellent efficiency combined with a compact size. The diameter of the toroid is 112 mm, and the height is 47 mm, making it suitable for installations where space is limited.

Operating frequency ranges from 50 Hz to 60 Hz, with a maximum operating temperature of 40°C, ensuring reliability under typical industrial environmental conditions. The termination type is via leads for flexible connection options, and the package includes a full mounting kit for straightforward installation.

Notable benefits include a very low level of radiated magnetic field, very low induced noise, and reduced iron losses, making it ideal for sensitive electronic equipment, laboratory, industrial, manufacturing, and HVAC applications. The transformer is double insulated on primary leads and rigorously tested for electrical and flash safety, complying with international standards such as RoHS, UL506, EN61558, EN60950, EN60065, VDE 0551, VDE 0550, and BS415.

With superior quality materials and construction, this transformer supports both series and parallel configurations for primary and secondary windings, allowing versatile voltage options and output combinations suitable for a wide range of power supply needs.

Primary voltage supports both 230 V ac and 115 V options for versatile use. Secondary voltage provides 2 x 55 V ac outputs for dual circuit supply. Rated secondary current is 2.05 A ensuring stable performance. Compact design features a 112 mm diameter and 47 mm height.

Constructed with open toroid center and single primary winding type for efficiency. Operation frequency ranges between 50 Hz and 60 Hz. Maximum operating temperature is rated at 40°C for industrial safety. Includes lead termination type and comes with a full mounting kit for ease of installation.

Designed with low radiated magnetic field and minimal noise for sensitive applications. Complies with RoHS, UL506, EN61558 and other applicable standards.

This product is ideal for use in electronics manufacturing, power supply systems, laboratory instrumentation, industrial equipment, and HVAC control systems. It ensures quality and reliability in power transformations where low noise and high efficiency are required.
