Weidmüller LMF Series PCB Terminal Block, 12-Contact, 5.08 mm Pitch, Through Hole Mount, 400 V, 24 A Current 1330820000
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 400V |
| Brand | Weidmüller |
| Colour | Orange |
| Orientation | Straight |
| Current | 24A |
| Length | 63.58mm |
| Depth | 14.8mm |
| Width | 19.2mm |
| Mount Type | Through Hole |
| Series | LMF |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Standards/Approvals | UL, RoHS, CSA cURus |
| Number of Contacts | 12 |
| Minimum Wire Size mm² | 0.2mm² |
| Maximum Wire Size mm² | 2.5mm² |
| Minimum Wire Size AWG | 24AWG |
| Maximum Wire Size AWG | 12AWG |
| Wire Connection Method | Push-in |
Key Features
- Designed for push-in wire connection method ensuring secure and easy termination.
- Single row configuration for straightforward PCB mounting.
- Supports wire sizes ranging from 0.2 mm² to 2.5 mm² (24 AWG to 12 AWG).
- Durable orange-colored body ensuring visibility and easy identification.
- Equipped with integrated test point for convenient testing and maintenance.
- Available with 90° and 180° wire outlet directions for flexible wiring layouts.
- Constructed to meet UL, RoHS, and CSA cURus standards for safety and compliance.
- Compact dimensions of 63.58 mm length, 19.2 mm width, and 14.8 mm depth optimize PCB space.
Product Description
Weidmüller 1330820000 LMF Series PCB Terminal Block, featuring 12 contacts and a 5.08 mm pitch, delivers high precision and efficiency in PCB electrical connections. Built with a robust orange housing and through hole mounting, this terminal block supports wire sizes from 0.2 mm² up to 2.5 mm², accommodating various conductor types with secure push-in terminal technology.
The integrated test point allows easy inspection and testing without disruption of circuits, while the choice of 90° or 180° wire outlet directions provides versatile wiring options suitable for diverse PCB layouts and industrial applications. Rated for currents up to 24 A at 400 V, it ensures reliable performance in commercial, industrial, and manufacturing electronic assemblies.
Compliance with UL, RoHS, and CSA cURus standards guarantees safety and environmental adherence, which is critical in industrial electronics. The compact form factor with dimensions 63.58 mm length, 19.2 mm width, and 14.8 mm depth facilitates efficient use of PCB space. Its push-in connection system eliminates the need for screws, reducing assembly time.
Designed for push-in wire connection method ensuring secure and easy termination. Single row configuration, simplifying PCB integration. Supports wire sizes from 0.2 mm² to 2.5 mm² (24 AWG to 12 AWG). Durable orange-colored body for high visibility.
Integrated test point for convenient circuit testing. Flexible 90° and 180° wire outlet directions. Complies with UL, RoHS, CSA cURus standards. Compact dimensions optimize PCB real estate.
The Weidmüller LMF Series PCB Terminal Block is ideal for use in electronic manufacturing, industrial control systems, telecommunications equipment, and other applications requiring durable and reliable PCB connections. This product ensures high integrity electrical paths with easy and repeatable assembly, supporting automated production environments.
Explore the wider Weidmüller range for complementary electronic components and connectors on EnvMart for comprehensive industrial and electronic solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a maximum current rating of 24 A.
It is rated for a voltage of 400 V.
It supports wire sizes ranging from 0.2 mm² to 2.5 mm² (24 AWG to 12 AWG).
The pitch of this terminal block is 5.08 mm.
It uses through hole mounting for installation.
The dimensions are 63.58 mm in length, 19.2 mm in width, and 14.8 mm in depth.
It features a push-in wire connection method for secure termination.
Yes, it is equipped with an integrated test point for convenient testing and maintenance.
The housing is orange, providing high visibility.
It complies with UL, RoHS, and CSA cURus standards.
This model features 12 contacts.
It is available with 90° and 180° wire outlet directions for flexible wiring layouts.
