Weidmüller LMF Series PCB Terminal Block 2-Contact 5.08 mm Pitch Through Hole 400V 24A 1330710000
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 400V |
| Brand | Weidmüller |
| Colour | Orange |
| Orientation | Straight |
| Current | 24A |
| Length | 12.78mm |
| Depth | 14.8mm |
| Width | 19.2mm |
| Mount Type | Through Hole |
| Series | LMF |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Standards/Approvals | UL, CSA cURus, RoHS |
| Number of Contacts | 2 |
| Minimum Wire Size mm² | 0.2mm² |
| Maximum Wire Size mm² | 2.5mm² |
| Minimum Wire Size AWG | 24AWG |
| Maximum Wire Size AWG | 12AWG |
| Wire Connection Method | Push-in |
Key Features
- Supports 2 contacts with a pitch of 5.08 mm for compact PCB design.
- Rated for a current of 24A and voltage up to 400V for reliable performance.
- Features through-hole mount type and straight orientation for easy PCB assembly.
- Accommodates wire sizes from 0.2 mm² to 2.5 mm² and AWG 24 to 12.
- Equipped with push-in connection system and integrated test point for efficient wiring and testing.
- Constructed in bright orange color for easy identification and compliance with standards UL, CSA cURus, and RoHS.
- Ideal for applications in electronics, industrial automation, and control systems requiring secure PCB connections.
Product Description
Weidmüller 1330710000 LMF Series PCB Terminal Block offers a high-quality solution for PCB wiring needs. This 2-contact terminal block features a 5.08 mm pitch and through-hole mount style that ensures durability and reliability. Designed to operate at up to 400V and 24A, it supports a broad wire size range from 0.2 mm² to 2.5 mm² and AWG 24 to 12, making it versatile for various electronic and industrial applications.
The push-in wire connection method facilitates quick and secure conductor installation, complemented by an integrated test point that allows for convenient testing without disconnection. Its bright orange coloring not only aids in visual identification but also meets international safety and environmental standards including UL, CSA cURus, and RoHS.
With dimensions of 12.78 mm length, 19.2 mm width, and 14.8 mm depth, the single-row terminal block is well suited for tight PCB layouts. The straight orientation and compact form factor make it an excellent choice for electronic manufacturing, industrial control panels, and automation systems where dependable connectivity is essential.
Supports 2 contacts with 5.08 mm pitch for compact and efficient PCB wiring. Push-in wire connection system allows fast and reliable conductor attachment. Integrated test point facilitates easy circuit testing without removal of wires.
Wide wire accommodation from 0.2 mm² to 2.5 mm² (AWG 24 to 12) enhances application flexibility. Complies with UL, CSA cURus, and RoHS standards ensuring safety and environmental conformity. Bright orange color improves visual identification and safety during assembly.
Designed for industrial, electronics manufacturing, control systems, and automation use cases. Explore EnvMart’s extensive range of PCB Terminal Blocks and electronic components for all your industrial and laboratory needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a voltage of 400V and a current of 24A, making it suitable for various applications.
The terminal block features a pitch size of 5.08 mm, which supports compact PCB design.
It accommodates wire sizes ranging from 0.2 mm² to 2.5 mm² and AWG 24 to 12, providing flexibility for different wiring needs.
The terminal block utilizes a push-in connection method, allowing for quick and secure conductor installation.
The dimensions of this unit are 12.78 mm in length, 19.2 mm in width, and 14.8 mm in depth.
It features a through-hole mount type, which ensures secure attachment to the PCB during assembly.
It complies with UL, CSA cURus, and RoHS standards, ensuring safety and environmental conformity.
The terminal block is designed with a straight orientation, facilitating easy installation on PCBs.
It is bright orange in color, which aids in visual identification and compliance with safety standards.
This model is ideal for use in electronics, industrial automation, and control systems that require secure PCB connections.
This terminal block supports 2 contacts, making it suitable for various wiring configurations.
The terminal block is manufactured in Switzerland, reflecting its quality and engineering standards.
