KEMET Film Capacitor R46 X2, ±20% Tolerance, 220 nF Capacitance, 275 V DC, 275 V AC, Through Hole Mount R46KN322040H1M

KEMET R46KN322040H1M Film Capacitor X2 is a high-performance through hole electronic component designed for EMI suppression in industrial, commercial, and consumer electronics. This capacitor features a metallized polypropylene film construction encapsulated within a self-extinguishing resin, providing reliability and safety in demanding applications.

With a capacitance of 220 nF and a tolerance of ±20%, the capacitor supports an operating voltage of 275 volts DC and AC, making it suitable for EMI noise filtering and suppression in power lines and electronic circuits. The radial lead terminals, spaced at 22.5 mm pitch with 30 mm lead length, facilitate easy and secure mounting on printed circuit boards.

Its operating temperature range of -40°C to 110°C ensures stability and durability in a variety of environmental conditions. The component conforms to RoHS standards and carries the X2 suppression classification, assuring safety and performance for AC line filtering applications.

The capacitor dimensions are 26.5 mm length, 15 mm height, and 6 mm width with lead diameters of 0.8 mm, enabling compact and effective PCB footprint design. It also exhibits excellent self-healing properties and a low dissipation factor of 0.1%, contributing to its efficiency and longevity.

Typical use cases include EMI suppression in industrial machines, power supplies, household appliances, and automotive electronics. The device belongs to the R46 series supporting capacitance values ranging from 0.01 μF to 10 μF and lead spacings from 10.0 to 37.5 mm, catering to a wide variety of electronic power and signal applications.

Rated for 275 V DC and 275 V AC voltage operation for EMI suppression. Metallized polypropylene film construction with self-extinguishing resin encapsulation. Radial lead terminal with 22.5 mm pitch and 30 mm lead length.

Operating temperature range from -40°C to 110°C for broad environment suitability. RoHS compliant and X2 suppression class, ensuring safety and environment standards. Compact size and low dissipation factor (0.1%) enhance efficiency and space utilization.

Self-healing properties increase reliability in electronic circuits. Ideal for use in industrial, laboratory, commercial, automotive, and power electronics. Explore additional Film Capacitors and similar electronic components at EnvMart for your design and manufacturing needs.
