Samtec TSW Series Straight Through Hole Pin Header 10 Contacts 2.54 mm Pitch 2 Row Unshrouded TSW-105-07-F-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 465V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4.7A |
| Model | TSW-105-07-F-D |
| Mount Type | Through Hole |
| Special Features | Many options for optimizing cost and performance with platings and ruggedizing features |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Contact System | .025" (0.635 mm) square post |
Key Features
- The connector features 10 male contacts with Gold-plated Phosphor Bronze material.
- Designed for through-hole mounting and solder termination.
- Suitable for board-to-board and wire-to-board connector systems.
- Housing is made of durable glass filled polyester, unshrouded for easy access.
- Operates reliably between -55°C and 125°C temperature range.
- Rated for 465V voltage and 4.7A current carrying capacity.
- The contact system utilizes 0.025" (0.635 mm) square posts for secure connections.
- Extended Life Product™ durability with high mating cycles and excellent performance in mixed flowing gas environments.
Product Description
Samtec TSW-105-07-F-D is a high-quality straight through hole pin header designed for robust electrical connections in industrial and commercial electronics applications. This pin header features 10 female contacts arranged in 2 rows with a 2.54 mm pitch, making it compatible with standard PCB layouts.
Constructed with a glass filled polyester housing, this unshrouded connector ensures durability and ease of access. The gold-plated phosphor bronze contacts provide excellent conductivity and resistance to corrosion, supporting a current rating of 4.7A and voltage rating of 465V. It operates efficiently within a wide temperature range from -55°C to 125°C, suitable for demanding environments.
The TSW series is an Extended Life Product™ that meets stringent industry standards with long durability, capable of withstanding 250 to 2,500 mating cycles and exposure to mixed flowing gas, making it optimal for extended service life.
Termination is by through-hole soldering, supporting secure mounting and reliable connectivity for both board-to-board and wire-to-board systems. This connector is ideal for applications in electronics manufacturing, industrial control systems, and PCB assembly lines.
The connector has 10 gold-plated contacts with phosphor bronze for high conductivity. Housing material is glass filled polyester, unshrouded design for versatility. Rated for 4.7 amps and 465 volts operation. Wide operating temperature range from -55°C to 125°C ensures durability.
Square post contact system of 0.025" (0.635 mm) enhances mechanical strength. Straight orientation supporting through-hole mounting and solder termination. Applications include industrial electronics, PCB connectors, and equipment manufacturing.
With reliable performance and versatile features, the Samtec TSW-105-07-F-D pin header is a trusted choice for precision PCB hardware. Explore our Electronics Components category on EnvMart for more specialized connectors and related products.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a maximum current of 4.7A and a voltage rating of 465V.
The pin header features 10 male contacts arranged in 2 rows with a pitch of 2.54 mm.
It operates efficiently within a temperature range of -55°C to 125°C.
The housing is made of glass filled polyester, and the contacts are constructed from gold-plated phosphor bronze.
Termination is achieved through-hole soldering, which supports secure mounting and reliable connectivity.
It utilizes a contact system with 0.025" (0.635 mm) square posts for enhanced mechanical strength.
This pin header is suitable for both board-to-board and wire-to-board connector systems.
It is designed to support between 250 to 2,500 mating cycles, ensuring long-term durability.
This model is unshrouded, allowing for easier access during installation.
The connector has a straight orientation, which is suitable for through-hole mounting.
The country of origin for this pin header is India.
It offers many options for optimizing cost and performance with various platings and ruggedizing features.
