Samtec ASP Series Straight Surface PCB Socket 400-Contact 4 Row 1.27 mm Pitch Solder ASP-134603-01
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | 339V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 2.7A |
| Model | ASP-134603-01 |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Copper |
| Series | ASP |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 4 |
| Pitch | 1.27mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold |
| Number of Contacts | 400 |
| Contact Gender | Male |
| Connector System | Board-to-Board |
| Stacking Height | 10mm |
Key Features
- This PCB socket supports a current rating of 2.7A for efficient power handling.
- The socket is mounted on the surface and oriented straight for easy installation.
- It is constructed from liquid crystal polymer housing ensuring durability.
- Featuring gold plated copper contacts for optimal conductivity and corrosion resistance.
- Operating temperature range is from -55°C to 125°C making it suitable for diverse environments.
- Compatible with a voltage rating of 339V for varied electronic applications.
- Designed with a stacking height of 10mm and 1.27 mm row pitch for compact assembly.
- Meets RoHS standards confirming compliance with environmental safety regulations.
Product Description
Samtec ASP-134603-01 is a high-performance ASP Series Straight Surface PCB Socket designed for board-to-board connector applications requiring 400 contacts arranged in 4 rows with a 1.27 mm pitch. The solder termination type allows for robust connections on printed circuit boards.
The socket provides a current rating of 2.7 amperes and supports voltages up to 339 volts, making it ideal for demanding electronic circuits in industrial, manufacturing, and commercial electronic systems.
The housing is made from liquid crystal polymer which offers excellent durability and thermal stability. Gold-plated copper contacts ensure exceptional electrical conductivity and resistance to oxidation, maintaining signal integrity over prolonged usage.
Operating temperature ranges from -55°C to 125°C, accommodating harsh environmental conditions commonly encountered in laboratory and industrial settings. The straight orientation and surface mount design facilitate simple and exact placement on PCB assemblies.
Current rating of 2.7A for reliable power transmission. Surface mount with straight orientation for precise PCB integration. Housing material: Liquid crystal polymer for mechanical and thermal strength. Gold plated copper contacts improve conductivity and corrosion resistance.
Wide operating temperature range from -55°C to 125°C. Rated voltage of 339V suitable for diverse applications. Stacking height of 10mm supports compact multiple board assemblies. Complies with RoHS environmental standards.
Made in the United States, ensuring premium quality standards.
This Samtec PCB socket is widely used in electronics manufacturing, development laboratories, and commercial electronic products. It is suitable for industrial control systems, telecommunications equipment, and embedded systems requiring secure and durable board-to-board connections.
Explore more industrial-grade connectors and sockets by browsing the PCB Socket category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The current rating of this PCB socket is 2.7 amperes, suitable for efficient power handling in electronic applications.
It has a voltage rating of 339 volts, making it compatible with various electronic applications.
The operating temperature range is from -55°C to 125°C, accommodating harsh environmental conditions.
This model features a pitch of 1.27 mm and a stacking height of 10 mm, allowing for compact assembly in PCB designs.
The housing is made from liquid crystal polymer, and it features gold-plated copper contacts for optimal conductivity and corrosion resistance.
This PCB socket has a total of 400 contacts arranged in 4 rows, designed for board-to-board connections.
The socket utilizes a solder termination type, ensuring robust connections on printed circuit boards.
Yes, it complies with RoHS standards, confirming its adherence to environmental safety regulations.
The ASP-134603-01 has a straight orientation and is designed for surface mounting on PCBs.
It is widely used in electronics manufacturing, development laboratories, and commercial electronic products, particularly in industrial control systems and telecommunications equipment.
This PCB socket is manufactured in the United States, ensuring adherence to quality standards.
It is a board-to-board connector system, specifically designed for secure and durable connections between PCBs.
