Hirose DF3 Series Straight Surface PCB Header, 8 Contacts, 2 mm Pitch, 1 Row, Shrouded DF3EA-8P-2V(21)
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 250V |
| Brand | Hirose |
| Orientation | Straight |
| Current | 3A |
| Model | DF3EA-8P-2V(21) |
| Mount Type | Surface |
| Housing Material | Polyamide |
| Contact Material | Brass |
| Series | DF3 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2mm |
| Contact Plating | Tin |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board, Wire-to-Board |
Key Features
- Features a low profile design for compact electronic assemblies.
- Includes a friction locking mechanism that ensures a secure mating connection.
- Equipped with PCB mounting bosses for accurate positioning during soldering.
- Reinforced metal fittings provide secure attachment to the PCB and prevent joint peeling.
- Constructed with polyamide housing and brass contacts plated with tin for durability.
- Supports operating temperatures from -55°C up to 105°C for various environments.
- Designed for 250 V voltage rating and 3 A current capacity.
- Suitable for board-to-board and wire-to-board connector systems.
Product Description
Hirose DF3EA-8P-2V(21) is a straight surface mount technology (SMT) PCB header connector from the DF3 series featuring an 8-contact, 1-row, 2 mm pitch design and shrouded housing for enhanced protection. This component is specifically engineered to provide reliable and secure connections on printed circuit boards through its innovative friction locking mechanism.
The low profile form factor makes it suitable for space-constrained electronic applications while maintaining mechanical durability. The polyamide housing material combines strength with insulation properties, and brass contacts plated with tin ensure excellent conductivity with corrosion resistance.
PCB mounting bosses facilitate accurate and repeatable positioning during the soldering process, improving assembly quality. In addition, reinforced metal fittings on either side of the housing secure the connector firmly to the PCB to prevent peeling around solder joints even under mechanical stress.
Operating temperature range from -55°C to 105°C allows this connector to perform effectively in diverse environmental conditions. It supports a rated voltage of 250 V and a current rating of 3 A, suitable for various electronic equipment needs.
Low profile design for compact PCB assemblies. Friction locking mechanism for stable connector mating. PCB mounting bosses for precise placement during soldering. Reinforced metal fittings secure the header to the PCB. Polyamide housing and tin-plated brass contacts.
Wide operating temperature range from -55°C to 105°C. Rated at 250 V voltage and 3 A current. Supports board-to-board and wire-to-board systems. Ideal for business equipment such as copy machines and printers.
This Hirose DF3 series PCB header is well suited to applications in industrial, commercial, and office electronic equipment manufacturing. Its robust construction and precise engineering contribute to durable and reliable electrical connections.
Explore other high-quality PCB Headers and related connectors on EnvMart for diverse electronic component needs and professional projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Hirose DF3EA-8P-2V(21) PCB header has a voltage rating of 250 V.
This model supports a current capacity of 3 A.
The contacts of this PCB header are spaced at a pitch of 2 mm.
It features a polyamide housing and brass contacts that are plated with tin.
The operating temperature range for this connector is from -55°C to 105°C.
This PCB header has 8 contacts.
This model uses surface mounting (SMT) for installation.
It supports both board-to-board and wire-to-board connector systems.
The orientation of this PCB header is straight.
The termination type for this connector is solder.
Yes, it includes a friction locking mechanism that ensures a secure mating connection.
The country of origin for this product is Japan.
