KEMET R53B Film Capacitor, 680 nF, ±10%, 800V DC, 350V AC, Through Hole, R53BN36805000K
Specifications
| Country of Origin | China |
|---|---|
| Display | screen |
| Brand | KEMET |
| Height | 20mm |
| Length | 26.5mm |
| Model | R53BN36805000K |
| Packaging | Tape & Reel |
| Width | 11mm |
| Mount Type | Through Hole |
| Series | R53B |
| Maximum Operating Temperature | 125°C |
| Tolerance | ±10 % |
| Capacitance | 680nF |
| Minimum Operating Temperature | -40°C |
| Dissipation Factor | 0.3% |
| Standards/Approvals | IEC 60384-14 |
| Package/Case | Plastic |
| Pin Count | 2 |
| Rated AC Voltage | 350V ac |
| Rated DC Voltage | 800V dc |
| Lead Pitch | 22.5mm |
| Automotive Standard | AEC-Q200 |
Key Features
- This film capacitor offers 680 nF capacitance with ±10% tolerance.
- Rated for 800V DC and 350V AC operation, suitable for demanding electronic circuits.
- Through hole mounting type enables secure installation on PCBs.
- Constructed with metallized polypropylene film for enhanced performance.
- Boxed in plastic meeting UL94 V-0 for flame retardance and durability.
- Qualified to AEC-Q200 automotive standard for reliability in harsh environments.
- Climatic category 40/110/56 per IEC 60068-1 with operating temperatures -40°C to 125°C.
- Lead pitch of 22.5 mm for easy placement.
Product Description
KEMET R53BN36805000K is a high-performance film capacitor engineered to deliver robust electrical characteristics in demanding applications. With a capacitance of 680 nF and a tolerance of ±10%, it provides reliable energy storage and filtering for electronic circuits.
The device features a rated voltage of 800V DC and 350V AC, making it suitable for industrial, automotive, and high-voltage electronics. Its through hole mounting design allows secure placement on printed circuit boards, accommodating both automated and manual assembly processes.
This film capacitor offers 680 nF capacitance with ±10% tolerance. Rated for 800V DC and 350V AC operation, suitable for demanding electronic circuits. Through hole mounting type enables secure installation on PCBs. Constructed with metallized polypropylene film for enhanced performance.
Boxed in plastic meeting UL94 V-0 for flame retardance and durability. Qualified to AEC-Q200 automotive standard for reliability in harsh environments. Climatic category 40/110/56 per IEC 60068-1 with operating temperatures -40°C to 125°C.
Lead pitch of 22.5 mm for easy placement. Low dissipation factor of 0.3% ensures efficient energy storage.
A plastic package ensures electrical insulation and mechanical protection, and compliance with UL94 V-0 fire safety standards. The capacitor is industrially tested and qualified to the AEC-Q200 automotive standard, meeting stringent reliability requirements.
With a climatic category of 40/110/56, this capacitor operates efficiently across a wide temperature range from -40°C to 125°C. The lead pitch of 22.5 mm enables compatibility with industry-standard PCB layouts. A low dissipation factor of 0.3% guarantees efficient energy storage with minimal losses.
Applications include power electronics, motor drives, industrial automation, automotive electronic modules, and high-voltage protection circuits. Its self-healing property extends lifespan and ensures stable operation under varying environmental conditions.
KEMET R53BN36805000K capacitors are ideal for use in manufacturing, laboratory instrumentation, commercial electronics, and harsh environment installations. Explore the EnvMart Film Capacitors category for additional models and brands suited for your projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a capacitance value of 680 nF with a tolerance of ±10%.
The KEMET R53B is rated for 800V DC and 350V AC operation.
It operates within a temperature range of -40°C to 125°C.
This model features a through hole mounting type, allowing secure installation on printed circuit boards.
The lead pitch is 22.5 mm, which facilitates compatibility with standard PCB layouts.
It has a low dissipation factor of 0.3%, ensuring efficient energy storage.
It is constructed with metallized polypropylene film and housed in a plastic package that meets UL94 V-0 standards for flame retardance.
Yes, it is qualified to the AEC-Q200 automotive standard, ensuring reliability in harsh environments.
It complies with IEC 60384-14 standards, ensuring it meets specific performance criteria for film capacitors.
The dimensions are 26.5 mm in length, 11 mm in width, and 20 mm in height.
It is suitable for applications in power electronics, motor drives, industrial automation, and automotive electronic modules.
It is packaged in tape and reel format, which is suitable for automated assembly processes.
