Vishay CMOS Quad Analogue Switch 4 SPST, 16-Pin SOIC DG442LEDY-GE3

Name: Vishay CMOS Quad Analogue Switch 4 SPST, 16-Pin SOIC DG442LEDY-GE3
Brand: Vishay
SKU: 92970



Category Multiplexer & Demultiplexer ICs Brand Vishay Condition New

Specifications

Country of Origin	Philippines
Brand	Vishay
Height	1.55mm
Length	10mm
Model	DG442LEDY-GE3
Width	4mm
Mount Type	Surface
Output type	CMOS/TTL
Series	DG442LE
Configuration	Quad SPST
Maximum Operating Temperature	85°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Standards/Approvals	RoHS
Pin Count	16
Number of Elements per Chip	4
Maximum Supply Voltage	16V
Logic Family	CMOS
Minimum Supply Voltage	-3V
Maximum On State Resistance	140Ω

Key Features

Offers four single-pole single-throw (SPST) switches with CMOS logic family.
16-pin SOIC surface mount package ensures easy integration onto PCBs.
Wide supply voltage range from -3V minimum to 16V maximum for versatile designs.
Low maximum on-state resistance of 140Ω for minimal signal loss.
Operating temperature range from -40°C to 85°C suitable for varied environments.
Automotive standard compliance not required for general electronic usage.
Compact dimensions of 10mm x 4mm x 1.55mm support space-constrained layouts.
RoHS approved for safe use in industrial and commercial products.

Product Description

Vishay DG442LEDY-GE3 CMOS Quad Analogue Switch is engineered for high precision signal routing, offering four independent SPST switches per chip. This component comes in a compact 16-pin SOIC surface-mount package, providing reliable performance for demanding electronic system applications.

With a wide supply voltage range from -3V to 16V and integrated CMOS/TTL output type, the DG442LEDY-GE3 delivers excellent compatibility across various platforms. The device's low on-state resistance of a maximum of 140Ω ensures efficient signal transfer without significant loss.

The switch's broad operating temperature range (-40°C to 85°C) makes it suitable for deployment in industrial, laboratory, and commercial environments. Its robust design features include RoHS compliance, making it an ideal choice for designers seeking environmentally safe options.

Advanced surface mounting, quad SPST configuration, and support for up to four elements per chip enable flexible design architectures, especially in complex multiplexing or demultiplexing signal circuits.

Offers four single-pole single-throw (SPST) switches for versatile analogue input and output switching. CMOS logic family delivers low power consumption and high noise immunity. Suitable for integration in test equipment, industrial control systems, and computer peripheral devices.

16-pin SOIC packaging provides ease of assembly and use in high-density applications. Guaranteed maximum on-state resistance of 140Ω ensures performance in precision circuits. Wide supply voltage range (-3V to 16V) supports both standard and portable instrument requirements.

Temperature resilience from -40°C to 85°C offers compatibility with harsh operating conditions. RoHS compliant construction addresses environmental and regulatory needs.

Industrial and laboratory designers will find this device essential for applications requiring reliable, high-accuracy analogue switching. Common use cases include automated test equipment, signal multiplexing, and control circuits in embedded systems.

Explore more Vishay semiconductors and Multiplexer & Demultiplexer ICs on the EnvMart platform to enhance your electronic design and innovation capabilities.

Explore more products in our Multiplexer & Demultiplexer ICs category.
