TDK-Lambda Switching Power Supply 12V DC, 5A, 60W, PCB Mount, 90 - 264V AC Input, KMS60A-12
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | TDK-Lambda |
| Power | 60W |
| Efficiency | 90% |
| Length | 3.5mm |
| Model | KMS60A-12 |
| Depth | 27mm |
| Gross Weight | 280g |
| Width | 63.5mm |
| Mount Type | PCB |
| Series | KMS60A |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Maximum Input Voltage | 370, 264V dc |
| Maximum Output Voltage | 12V dc |
| SMPS Output Current | 5A |
| Minimum Input Voltage | 90V ac |
Key Features
- Provides 12V DC output at a maximum current of 5A.
- Compact and lightweight for easy PCB integration.
- Operates over a wide input range of 90 - 264V AC and up to 370V DC.
- High efficiency rated up to 90% for low operational losses.
- Fully encapsulated construction with medical safety certifications.
- Supports operation in temperatures from -40°C to 85°C for demanding environments.
- Single output, Class II rated - no ground connection required.
- Complies with major global safety and EMC standards.
Product Description
The TDK-Lambda KMS60A-12 is a high-performance switching power supply designed to deliver 12V DC at a steady 5A output, providing a total continuous power of 60W. This module is ideally suited for applications requiring compact design and reliable power conversion in both industrial and medical device environments.
Engineered for PCB mounting, the KMS60A-12 offers an impressive efficiency of up to 90%, ensuring minimal energy loss and reduced heat generation during operation. Its fully encapsulated construction provides robust protection for sensitive internal components, making it suitable for harsh or high-reliability uses.
Supporting a wide universal input range of 90 - 264V AC and up to 370V DC, this power supply provides maximum flexibility across various installation locations and mains conditions. The single output simplifies system integration, while Class II insulation means grounding is not required for safety conformity.
This model operates across an extended temperature range from -40°C to 85°C, maintaining stability and reliability in demanding environments. Built-in protections safeguard against overvoltage, overcurrent, and thermal overloads. With its medical safety certification (with 4kV AC input/output), the unit is well-suited for integration into medical equipment as well as industrial systems and automation.
The KMS60A-12 meets rigorous international standards for EMC and safety, including EN 61000, CE, VCCI-B, IEC/UL/CSA/EN 62368-1, and FCC Class B compliance, ensuring minimal electromagnetic interference and acceptance for global applications.
Typical use cases include portable medical devices, control panels, test and measurement systems, and any low power electronic system requiring continuous and reliable DC supply from AC mains or DC input.
The power supply’s dimensions (63.5 mm width x 27 mm depth x 3.5 mm length) and weight of approximately 280g facilitate integration into compact enclosures or panels where space is at a premium.
Explore additional TDK-Lambda power supply solutions in the EnvMart Switching Power Supply category for more options suited to your exact application needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The KMS60A-12 provides a maximum output current of 5A at 12V DC.
It has an efficiency rating of up to 90%, ensuring minimal energy loss during operation.
This model operates over a wide input range of 90 - 264V AC and up to 370V DC.
The dimensions of the KMS60A-12 are 63.5 mm in width, 27 mm in depth, and 3.5 mm in length.
This unit weighs approximately 280g, making it suitable for compact installations.
It operates effectively in temperatures ranging from -40°C to 85°C.
The KMS60A-12 is designed for PCB mounting, facilitating easy integration into various systems.
No, this model is Class II rated, meaning it does not require a ground connection for safety.
It complies with major global safety and EMC standards, including EN 61000, CE, and IEC/UL/CSA/EN 62368-1.
This model is suitable for portable medical devices, control panels, and test and measurement systems.
It includes protections against overvoltage, overcurrent, and thermal overloads to safeguard its operation.
