WEG CWC Series Contactor 24V AC Coil 3-Pole 9A 4kW 690V AC DIN Rail CWC09-01-30D02



Category Power Contactors Brand WEG Condition New

Specifications

Country of Origin	Brazil
Brand	WEG
Function	Motor Control
Length	58mm
Model	CWC09-01-30D02
Depth	52mm
Width	45mm
Mount Type	DIN Rail
Series	CWC
Power Rating	4kW
Maximum Operating Temperature	55°C
Minimum Operating Temperature	-25°C
Terminal type	Screw
Number of Poles	3
Standards/Approvals	UL, RoHS, IEC
Contact Voltage	690V ac
Coil Voltage	24V ac
Normal State Configuration	3 NO
Contact Current	9A
Number of Auxiliary Contacts	1
Auxiliary Contact Configuration	1 NC
Operational Current Ie	9A
Control Circuit Voltage Uc	24V ac
Contactor Application	Motor Control
Pole and Throw Configuration	3PST

Key Features

Compact modular contactor designed for switching electric motors up to 4kW.
Equipped with a 24V AC control coil for reliable motor control applications.
Features three normally open main contacts and one normally closed auxiliary contact.
Rated for operational voltages up to 690V AC and currents up to 9A.
Mounts easily on DIN rails and has screw terminal connections for secure wiring.
Provides auxiliary contact configuration of 1 NC for expanded control and signaling options.
Operates reliably across a temperature range of -25°C to 55°C and meets UL, RoHS, and IEC standards.

Product Description

The WEG CWC09-01-30D02 is a premium compact contactor from WEG's CWC Series designed for high-reliability motor control and switching applications in industrial, commercial, and automation settings. Its 24V AC coil offers responsive control, making it ideal for integration with a variety of system voltages, while supporting streamlined operation for electric motors rated up to 4kW at 400V.

Constructed with robust materials, this contactor ensures long service life and consistent performance. The modular CWC design saves space in control panels, and DIN rail mounting simplifies installation and replacement. Screw-type terminals guarantee secure and reliable connections, essential for high-duty and continuous operation environments.

Featuring three normally open (3 NO) main contacts, the CWC09-01-30D02 is well-suited for direct-on-line motor starting and switching duties. An integrated normally closed (1 NC) auxiliary contact supports flexible control logic, status signaling, or safety interlocks. Rated at 9A operational current and up to 690V AC, this contactor accommodates a broad range of machinery and automation needs.

The device operates reliably in environments as cold as -25°C and as hot as 55°C, reflecting its suitability for harsh and demanding industrial settings. Built to meet international safety and performance standards including UL, RoHS, and IEC, the WEG CWC contactor delivers peace of mind for maintenance engineers and specifiers.

Typical applications include industrial machines, HVAC equipment, water pumps, fans, compressors, conveyors, and automated process systems, where control reliability and electrical durability are paramount. Its compact housing is especially beneficial for dense control panels, and the versatility of DIN rail or panel mounting maximizes installation flexibility.

For those requiring consistent and repeatable motor start-stop operations, as well as auxiliary switching or signaling, the WEG CWC09-01-30D02 stands out for its robust construction, flexibility, ease of integration, and adherence to global safety standards. Its proven track record in industrial and commercial environments underscores its reliability and widespread acceptance.
