Schneider Electric TeSys K Reversing Contactor 240V AC Coil 3-Pole 9A 4kW 690V AC LC2K0910U7

The Schneider Electric LC2K0910U7 is a compact TeSys K series reversing contactor engineered for reliable control of motors and resistive loads. This model operates with a 240V AC coil and provides a three-pole switching capability, each with a normally open (NO) configuration, enabling control of equipment rated up to 9A and 690V AC. With a power rating of 4kW at 240V AC, the contactor is well suited for small to medium-sized industrial motor circuits and multiple automation scenarios.

Equipped with a built-in mechanical interlock and pre-wired reversing power connections, the LC2K0910U7 ensures only one contactor is activated at any time, contributing to both operational safety and circuit reliability. The device includes one auxiliary normally open contact, broadening its control flexibility for auxiliary devices or feedback circuits. It is designed for easy mounting via a DIN rail or screws, and utilizes robust screw clamp terminals. The IP20 finger-safe terminals carry both North American and International markings for hassle-free wiring and enhanced protection against accidental electric contact.

The contactor’s compact form factor (90mm width, 58mm length, 57mm depth) allows for high-density panel installations, a critical consideration for panel builders and OEMs. It maintains consistent performance even in challenging thermal conditions with maximum operating temperature up to 50°C and supports high operating rates, up to 600 cycles per hour in AC-3 applications. The LC2K0910U7 complies with international standards including IEC, UL, CSA, CCC, and EAC, as well as RoHS for environmental responsibility, making it suitable for global industrial deployments.

Typical applications include industrial machines, HVAC systems, manufacturing automation lines, conveyors, compressors, pumps, and control panels. This reversing contactor is especially useful for installations requiring frequent direction changes or robust motor circuit protection, thanks to its mechanical and electrical interlocking and double-break pole design. Flexible control circuit adaptation ensures compatibility with a broad spectrum of industrial automation and control system requirements.

The LC2K0910U7 is manufactured in France and showcases Schneider Electric’s commitment to sustainability with its designed-for-disassembly approach. The product integrates seamlessly into new and retrofit installations across industrial, commercial, and process automation domains.

Wide operating voltage and power rating suitable for diverse control applications. Mechanical interlock mechanism for safe reversal of motors. IEC, UL, CSA, CCC, EAC, and RoHS certifications. Resilient construction for demanding operational environments.

Simple installation and maintenance with finger-safe screw terminals and compact footprint. For more industrial automation components, explore the Power Contactors category or browse other Schneider Electric solutions on EnvMart.
