Mean Well DALI Dimmable LED Driver 48V 150W IP67

Free Delivery in India | Lowest Global Shipping Charges

Mean Well DALI Dimmable LED Driver 48V 150W IP67

Name: Mean Well DALI Dimmable LED Driver 48V 150W IP67
Brand: MEAN WELL
SKU: 87942



Category LED Driver Brand MEAN WELL Condition New

Specifications

Country of Origin	China
Brand	MEAN WELL
Model	IP67
IP Rating	IP67
Mount Type	Screw
Series	ELG-150
Configuration	Encapsulated
Sub Type	LED Driver
Operating Modes	Constant Current/Constant Voltage
Number of outputs	1
Terminal type	Wire
Maximum Output Power	150W
Input Voltage	180, 305, 254, 431V ac
Output Voltage	48V
Power Dissipation	150.2W
Standards/Approvals	CB, CE:CCC, cULus Recognized, EN61347-1, EN61347-2-13, EN62384, ENEC, PFC, UL8750
Dimming Operation	DALI
Primary Type	AC-DC, DC-DC
Driver Current	900mA
Standards/Approvals CB, CE	CCC, cULus Recognized, EN61347-1, EN61347-2-13, EN62384, ENEC, PFC, UL8750

Key Features

Delivers a constant current or voltage output for LED lighting applications.
Supports DALI dimming for integration with intelligent lighting control systems.
IP67 rated, offering superior dust and water resistance for harsh environments.
Wide input range from 180V to 431V AC with active power factor correction.
Encapsulated full metal housing ensures high reliability and heat dissipation.
Compact screw-mount design for versatile installation options.
Suitable for LED street lights, bay lighting, floodlighting, and architectural applications.
Operates in fanless mode for enhanced efficiency and long service life.

Product Description

The Mean Well ELG-150-48DA LED driver is a high-performance, DALI dimmable power supply designed for demanding industrial and outdoor lighting applications. With a maximum output power of 150W, it provides a constant 48V DC output at up to 900mA, accommodating both constant current and constant voltage operational modes. This versatility allows the driver to meet diverse requirements in professional LED lighting systems.

The driver features a robust, fully encapsulated metal housing, earning it a high IP67 rating. This level of protection ensures excellent resistance to water, dust, and harsh environmental conditions, making it ideal for outdoor installations such as street lighting, bay and floodlights, and architectural illumination where reliability is essential.

Incorporating DALI-compatible dimming, the ELG-150-48DA enables seamless integration with advanced lighting management systems. The unit accepts a wide input voltage range from 180V to 431V AC, simplifying compatibility in global applications and offering flexibility for varying power supplies. Built-in active power factor correction (PFC) ensures efficient power usage and compliance with energy standards.

The driver supports both potentiometer and PWM signal dimming controls. Despite its significant output capability, the fanless design ensures quiet operation and contributes to an extended lifespan. The screw-mount configuration and wire terminal connections provide straightforward and secure installation in diverse environments.

For demanding commercial and industrial lighting projects - like LED street lamps, bay lighting in warehouses, and exterior architectural projects - the Mean Well ELG-150-48DA delivers reliable power, flexible dimming options, and long-term durability. Its compliance with major global safety and performance standards further enhances its suitability for professional lighting engineers and contractors seeking robust, low-maintenance LED power solutions.

Explore a wide selection of LED Drivers and lighting solutions from Mean Well and other leading brands in the Electronics & Electricals category on EnvMart.
