STMicroelectronics 4-Element Uni-Directional TVS Diode, Common Anode, 150 W, 5-Pin SOT-323 ESDA25W5
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1mm |
| Length | 2.2mm |
| Model | ESDA25W5 |
| Width | 1.35mm |
| Mount Type | Surface |
| Series | ESDAxxxWx |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-323 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 5 |
| Number of Elements per Chip | 4 |
| Diode Configuration | Common Anode |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 25V |
| Maximum Reverse Stand-off Voltage Vwm | 24V |
| Peak Pulse Power Dissipation Pppm | 150W |
| Test Current It | 1mA |
| Maximum Reverse Leakage Current | 1μA |
Key Features
- Offers ESD protection with uni-directional transient suppression.
- Features four elements per chip, improving circuit protection density.
- Designed with a Common Anode configuration for efficient PCB integration.
- Supports a minimum breakdown voltage of 25 V and maximum reverse stand-off voltage of 24 V.
- Supplied in a compact SOT-323 package with a small footprint for space-constrained designs.
- Rated for -40°C to 125°C operation, suitable for demanding environments.
- Peak pulse power dissipation of 150 W ensures robust surge handling.
Product Description
STMicroelectronics ESDA25W5 is a high-performance uni-directional transient voltage suppressor (TVS) diode array designed to protect sensitive electronic circuits from electrostatic discharge (ESD) and other voltage transients. Featuring four diode elements per chip in a Common Anode configuration, this device is engineered for robust surge protection and transient suppression.
Its surface-mount SOT-323 package with five pins allows for straightforward integration into densely populated printed circuit boards. With a minimum breakdown voltage of 25 V and a maximum reverse stand-off voltage of 24 V, the ESDA25W5 provides reliable protection for digital and analog interfaces against fast voltage spikes. The small form factor, with dimensions of 2.2 mm length, 1.35 mm width, and 1 mm height, enables usage in space-limited applications where high protection density is required.
This TVS diode supports a peak pulse power dissipation of 150 W, ideal for shielding electronic components from severe ESD events and transient surges. With a maximum reverse leakage current of only 1 μA and a wide operating temperature range from -40°C to 125°C, it ensures dependable performance across diverse industrial, commercial, and automotive environments, although it does not meet automotive standards for qualification.
ESDA protection is realized with uni-directional characteristics, making the device suitable for safeguarding input/output lines, microcontroller interfaces, and communication ports. The ESDA25W5 is well-suited for use in industrial automation, medical electronics, consumer devices, and laboratory instrumentation requiring robust overvoltage protection.
For production, the ESDA25W5 is typically supplied on a reel, facilitating automated placement and high-volume PCB manufacturing. The combination of its compact SOT-323 package, four-chip element density, and high pulse power handling makes it a preferred choice for designers seeking reliable, small-footprint ESD solutions.
Explore more TVS Diodes and circuit protection products from STMicroelectronics in the Semiconductor category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The ESDA25W5 has a peak pulse power dissipation of 150 W, allowing it to handle severe ESD events and transient surges effectively.
This model has a minimum breakdown voltage of 25 V, providing reliable protection against voltage transients.
The SOT-323 package has dimensions of 2.2 mm in length, 1.35 mm in width, and 1 mm in height, making it suitable for space-constrained designs.
This model operates within a temperature range of -40°C to 125°C, making it suitable for various industrial and commercial applications.
The ESDA25W5 features four elements per chip, which enhances circuit protection density.
It is designed with a Common Anode configuration, facilitating efficient integration into printed circuit boards.
This model is a surface-mount device, allowing for straightforward integration into densely populated PCBs.
It is well-suited for safeguarding input/output lines, microcontroller interfaces, and communication ports in various electronic devices.
The test current for this TVS diode is 1 mA, which is used during its evaluation under specified conditions.
The country of origin for the ESDA25W5 is India, indicating its manufacturing location.
