Schneider Electric TeSys K Reversing Contactor 48V AC Coil, 3-Pole, 9A, 4kW, 690V AC Plate/Rail Mount LC2K09015E7
Specifications
| Country of Origin | France |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Resistive Load, Reversing |
| Length | 58mm |
| Model | LC2K09015E7 |
| Depth | 57mm |
| Width | 90mm |
| Mount Type | Plate, Rail Mount |
| Series | TeSys K |
| Power Rating | 4kW |
| Maximum Operating Temperature | 50°C |
| Minimum Operating Temperature | -25°C |
| Terminal type | Solder Pin |
| Number of Poles | 3 |
| Standards/Approvals | CSA, CCC, EAC, IEC, RoHS, UL |
| Contact Voltage | 690V ac |
| Coil Voltage | 48V ac |
| Normal State Configuration | 3 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 9A |
| Number of Auxiliary Contacts | 1 |
| Auxiliary Contact Configuration | 1 NC |
| Operational Current Ie | 9A |
| Control Circuit Voltage Uc | 48V ac |
| Contactor Application | Motor Control, Resistive Load |
| Pole and Throw Configuration | 3 |
Key Features
- Features a 48V AC coil for efficient voltage control.
- Offers 3-pole switching with 9A contact current and 4kW power rating.
- Supports up to 690V AC contact voltage for high-voltage systems.
- Plate and rail mount options ensure versatile installation.
- Solder pin terminals allow integration with PCB assemblies.
- Configurable with 3 NO main poles and 1 NC auxiliary contact.
- Operates reliably from -25°C to 50°C ambient temperature.
- Electrical endurance up to 1.3 million cycles for AC-3 duty.
Product Description
Schneider Electric LC2K09015E7 TeSys K Reversing Contactor is a compact, high-performance industrial switching device engineered for precise motor rotation control and resistive load switching. Featuring a 48V AC coil, the contactor efficiently handles control voltage, making it suitable for automation panels and demanding industrial applications. The device utilizes a robust 3-pole configuration supporting a contact current of 9A and power rating of up to 4kW, enabling reliable operation of small three-phase motors and various machinery.
With a rated contact voltage of 690V AC, this contactor is compatible with high-voltage systems, providing flexibility across diverse installation environments. Its plate and rail mounting options simplify integration into control cabinets and equipment assemblies.
The contactor comes equipped with three main NO poles and one auxiliary NC contact, catering to complex control logic requirements in control circuits. Its operational reliability is maintained between ambient temperatures of -25°C to 50°C, and the device boasts an electrical endurance rating of up to 1.3 million cycles (AC-3 duty), supplemented by a mechanical life expectancy of up to 5 million cycles.
Short-time withstand ratings ensure safety under transient faults, with tolerance for 90A (1s) and 45A (1min) at 50°C. The device’s compact footprint - 58mm length, 90mm width, 57mm depth - enables easy incorporation into equipment with space constraints.
Typical applications include reversing small three-phase motors, industrial drives, automation panels, and controlling resistive loads in technical environments. 48V AC coil provides consistent voltage control and reduces complexity in installations.
Rated for 9A contact current and 4kW power, supporting challenging industrial loads. 690V AC contact voltage ensures compatibility with high-voltage industrial systems. Flexible plate and rail mounting for easy installation and maintenance.
3 NO main poles and 1 NC auxiliary contact accommodate versatile control logic. Endures up to 1.3 million electrical switch cycles (AC-3), with a mechanical life of 5 million cycles. Short-duration overload performance: withstands 90A (1s) and 45A (1min) at 50°C.
Suitable for reversing applications in automation panels and industrial drive systems. Compact dimensions optimize cabinet usage and support dense installations. Explore advanced industrial control products in the Relays & Contactors category or browse Schneider Electric’s full range of automation solutions at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The power rating of this model is 4kW, making it suitable for various industrial applications.
It supports a maximum contact voltage of 690V AC, which is suitable for high-voltage systems.
The contact current rating is 9A, allowing it to handle a range of industrial loads effectively.
This reversing contactor uses a 48V AC coil for efficient voltage control in automation applications.
The dimensions are 58mm in length, 90mm in width, and 57mm in depth, allowing for compact installation.
It features a 3-pole configuration, which is essential for motor control and resistive load applications.
The operational temperature range is from -25°C to 50°C, ensuring reliable performance in various environments.
It offers both plate and rail mounting options, providing flexibility for installation in control cabinets.
This unit includes one normally closed (NC) auxiliary contact, in addition to the three normally open (NO) main poles.
It complies with several standards including CSA, CCC, EAC, IEC, RoHS, and UL, ensuring safety and reliability.
It has an electrical endurance rating of up to 1.3 million cycles for AC-3 duty, which indicates its longevity in operation.
It is suitable for reversing small three-phase motors, industrial drives, and controlling resistive loads in automation panels.
