KEMET SPST Through Hole Reed Switch 300 mA, 110 V AC/DC, Tab Leads, OHD3-130M
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | KEMET |
| Length | 27mm |
| Model | OHD3-130M |
| Depth | 12.5mm |
| Width | 13.5mm |
| Mount Type | Through Hole |
| Contact Material | Nickel Iron Alloy |
| Series | OHD |
| Maximum Switching Current | 300mA |
| Maximum Operating Temperature | 150°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -20°C |
| Terminal type | Tab Leads |
| Contact Resistance | 150mΩ |
| Maximum Switching Power | 6W |
| Standards/Approvals | RoHS |
| Maximum Switching Voltage | 110V ac/dc |
Key Features
- Single pole single throw (SPST) contact configuration for reliable electrical switching.
- Supports maximum switching current of 300 mA for versatile application.
- Rated for up to 110 V AC/DC to accommodate power and signal control circuits.
- Tab leads designed for robust through-hole PCB mounting.
- Contact material is nickel iron alloy for enhanced conductivity and durability.
- Operates within a temperature range of -20°C to 150°C for environmental versatility.
- Provides high-speed response and extended operational life.
- Suited for temperature detection and overheating monitoring applications.
Product Description
KEMET OHD3-130M SPST Through Hole Reed Switch is a highly reliable, magnetically operated switch engineered for precise and rapid switching in industrial, electrical, and automation applications. It offers robust performance for both power and signal control systems.
This reed switch features a single pole single throw (SPST) contact arrangement, facilitating accurate on/off switching. The device is capable of handling up to 300 mA maximum switching current and operates at voltages up to 110 V AC/DC, allowing flexible integration in a wide range of electrical circuits.
Designed with tab leads for secure through-hole mounting, the OHD3-130M ensures stable installation in printed circuit boards and electrical assemblies. The contacts are made from a nickel iron alloy, which provides excellent electrical conductivity, minimizes resistance (150 mΩ), and improves durability for long-term operation.
The OHD3-130M is distinguished by its broad operational temperature range from -20°C to 150°C, making it suitable for environments subject to temperature extremes, including industrial, laboratory, and commercial settings. Its compact dimensions - 27 mm in length, 13.5 mm in width, and 12.5 mm in depth - support efficient space utilization within measurement, monitoring, and control devices.
The unique thermal guard design utilizes a proprietary ferromagnetic substance that responds to temperature changes, boosting reliability in atmospheric temperature detection and overheat monitoring for power transistors, modules, heaters, amplifiers, motors, HDDs, FDDs, and other electrical devices. The reed switch offers compatibility with extremely low to high signal power levels (0.1 mW to 6 W), making it versatile for signal and power switching.
Key applications include temperature monitoring, overheat protection, and automatic circuit activation in industrial automation, control panels, laboratory equipment, HVAC systems, and manufacturing lines. Its dust, explosion, and corrosion-proof nature enhances environmental durability and operational safety.
End users can browse EnvMart for more Reed Switches, capacitive and piezo switches, as well as solutions from KEMET for enhanced industrial and electronics automation performance.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum switching current for this model is 300 mA, allowing it to handle various electrical applications effectively.
It features a single pole single throw (SPST) contact configuration, which enables reliable on/off switching.
This unit has dimensions of 27 mm in length, 13.5 mm in width, and 12.5 mm in depth, facilitating compact installations.
It operates within a temperature range of -20°C to 150°C, making it suitable for various environmental conditions.
This reed switch is designed for through-hole mounting, which provides secure installation on printed circuit boards.
The contacts are made from nickel iron alloy, which enhances conductivity and durability.
It is rated for a maximum operating voltage of 110 V AC/DC, accommodating a variety of power and signal control circuits.
The contact resistance is 150 mΩ, which minimizes energy loss during operation.
It is suited for applications such as temperature monitoring, overheat protection, and automatic circuit activation in various industrial settings.
The maximum switching power for this model is 6 W, allowing it to manage a range of signal and power levels.
Yes, it complies with RoHS standards, ensuring it meets environmental safety regulations.
It features tab leads as its terminal type, which are designed for robust connections during installation.
