Samtec TSM Series Straight Surface Pin Header 4 Contacts 2.54 mm Pitch 2 Row Unshrouded Surface Mount TSM-102-02-L-DV

Free Delivery in India | Lowest Global Shipping Charges

Samtec TSM Series Straight Surface Pin Header 4 Contacts 2.54 mm Pitch 2 Row Unshrouded Surface Mount TSM-102-02-L-DV

Name: Samtec TSM Series Straight Surface Pin Header 4 Contacts 2.54 mm Pitch 2 Row Unshrouded Surface Mount TSM-102-02-L-DV
Brand: Samtec
SKU: 82157
Price: 0.63 USD
Availability: InStock



Category PCB Pin Header Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	475V
Brand	Samtec
Orientation	Straight
Current	4A
Model	TSM-102-02-L-DV
Mount Type	Surface
Special Features	Designed specifically for surface mount applications with many options to facilitate processing
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	TSM
Termination	Surface mount, mixed technology
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	4
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Board-to-Board
Mating Pin Length	8.13mm
Contact System	.025" (0.635 mm) square post

Key Features

Provides reliable board-to-board connections with a 2.54 mm pitch.
Features 4 gold-plated male contacts for enhanced conductivity and durability.
Unshrouded straight configuration with two rows facilitates integration in tight PCB layouts.
Constructed with a high-temperature liquid crystal polymer housing for robust performance.
Designed specifically for surface mount soldering, compatible with automated PCB assembly.
Rated for up to 4 A and 475 V to support a wide range of electronic applications.
Operating temperature range from -55°C to 125°C ensures suitability for demanding environments.
Mating pin length of 8.13 mm enables flexible board stacking and socket compatibility.

Product Description

The Samtec TSM-102-02-L-DV is a straight surface mount pin header from the TSM Series, engineered for board-to-board connection solutions in advanced electronic assemblies. This connector features 4 male gold-plated contacts arranged across 2 rows with a 2.54 mm pitch, providing a compact and reliable interconnect option for printed circuit boards.

Its unshrouded and straight design promotes ease of integration within densely populated PCB layouts, while the surface mount compatibility supports efficient automated soldering processes. The housing is made from high-temperature liquid crystal polymer, ensuring robust structural and thermal performance during assembly and operation.

The contacts are fabricated from phosphor bronze and finished with gold plating to deliver consistent signal transmission, corrosion resistance, and extended operational life. Rated for currents up to 4 amperes and voltage up to 475 volts, the header meets the demands of both signal and power applications in environments such as industrial automation, embedded systems, and advanced instrumentation.

Mating pin length of 8.13 mm enables flexible stacking and socket compatibility, allowing designers to tailor board configurations as needed. The connector operates in temperatures from -55°C to 125°C, supporting deployment in harsh conditions including industrial, laboratory, and manufacturing settings.

With its board-to-board system and male contact gender, the Samtec TSM-102-02-L-DV adapts to diverse electronic layouts, supporting a wide range of use cases: industrial control units, laboratory equipment, embedded systems, communication modules, and more. Its precision-engineered contacts and durable housing make it ideal for demanding high-density PCB designs.

Choose Samtec PCB Pin Headers for reliable performance in electronics manufacturing, prototyping, and assembly. Explore more industrial connector solutions in the EnvMart PCB Pin Header catalog.
