Samtec Straight Through Hole Pin Header, 4 Contacts, 1.27 mm Pitch, 1 Row, Unshrouded TMS-104-01-G-S
Specifications
| Country of Origin | China |
|---|---|
| Brand | Samtec |
| Orientation | Straight |
| Current | 5A |
| Model | TMS-104-01-G-S |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TMS |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 3.05mm |
| Mating Pin Length | 5.84mm |
| Contact System | .018" (0.46 mm) square post |
Key Features
- Offers a compact 1.27 mm pitch suitable for high-density PCB designs.
- 4-contact pin header, ideal for board-to-board connections in electronic assemblies.
- Unshrouded and single-row configuration ensures easy installation and compatibility.
- Straight through-hole mount type provides secure mechanical and electrical connection.
- Constructed with liquid crystal polymer housing for enhanced durability and thermal stability.
- Gold-plated phosphor bronze contacts guarantee reliable conductivity and corrosion resistance.
- Compatible with solder termination and features a tail pin length of 3.05 mm.
- Operating temperature range from -55°C to 125°C for diverse environments.
Product Description
Samtec TMS-104-01-G-S is a straight through hole pin header designed for precision PCB board-to-board interconnections. Featuring 4 contacts in a single row and a compact 1.27 mm pitch, this unshrouded connector is engineered for applications requiring space efficiency and reliable signal transmission. The through-hole mount allows robust mechanical retention and superior electrical connectivity between PCBs.
The housing is manufactured from liquid crystal polymer, providing exceptional durability and excellent thermal stability under both soldering and operational environments. Gold-plated phosphor bronze contacts ensure high conductivity, minimal signal loss, and resistance to oxidation, making the header ideal for demanding industrial and commercial electronics.
This pin header supports solder termination and includes a tail pin length of 3.05 mm, while the contacts are male for universal compatibility. The product operates in a wide temperature range from -55°C to 125°C, which makes it suitable for electronic systems exposed to varied ambient conditions.
Typical applications include industrial controllers, instrumentation, laboratory test equipment, PLC systems, and custom electronic assemblies where reliable board-to-board interfacing is critical. Its unshrouded, right-angle or vertical design supports optional polarization and is adaptable for single or double row layouts up to 100 pins.
Samtec TMS-104-01-G-S offers high-quality performance in environments ranging from manufacturing to research laboratories, and its compliance with RoHS makes it appropriate for modern electronics.
For additional PCB header products or to browse Samtec’s range, explore the Electronics & Electricals category at EnvMart.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pin header features a compact pitch of 1.27 mm, suitable for high-density PCB designs.
This model has 4 contacts arranged in a single row, designed for board-to-board connections.
The maximum operating temperature is 125°C, allowing it to function in diverse environments.
It supports solder termination, making it compatible with through-hole mounting.
The housing is constructed from liquid crystal polymer, which provides enhanced durability and thermal stability.
The tail pin length is 3.05 mm, facilitating secure connections on the PCB.
The contacts are made of gold-plated phosphor bronze, ensuring reliable conductivity and corrosion resistance.
This pin header is rated for a current of 5A, suitable for various electronic applications.
The minimum operating temperature is -55°C, allowing it to be used in low-temperature environments.
It utilizes a board-to-board connector system, ideal for interconnecting PCBs.
This model is unshrouded, which ensures easy installation and compatibility in various applications.
The mating pin length is 5.84 mm, providing a secure connection when interfacing with other components.
