Hioki Digital Multimeter DT4224
Specifications
| Country of Origin | Japan |
|---|---|
| DC Voltage Range | 600.0 mV to 600.0 V / 4 ranges / ±0.5 % rdg. ±5 dgt. accuracy |
| AC Voltage Range | 6.000 V to 600.0 V / 3 ranges / 40 Hz - 1 kHz / ±1.0 % rdg. ±3 dgt. (True RMS / crest factor 3) |
| Capacitance Range | 1.000 μF to 10.00 mF / 5 ranges / ±1.9 % rdg. ±5 dgt. accuracy |
| Resistance Range | 600.0 Ω to 60.00 MΩ / 6 ranges / ±0.9 % rdg. ±5 dgt. accuracy |
| Display | Main & Sub LCD (4 digits / max. 6000) / bar graph |
| Frequency range | AC V measurement - 99.99 Hz (≥5 Hz) to 9.999 kHz / 3 ranges / ±0.1 % rdg. ±2 dgt. accuracy |
| Diode Test | Open terminal voltage - ≤2.5 V / Testing current - ≤0.5 mA / Forward voltage threshold - 0.15 V to 1.5 V |
| Brand | HIOKI |
| Power Supply | 1× LR03 alkaline battery / 35h use (backlight OFF) |
| Dimensions | 72 × 149 × 38 mm |
| Model | DT4224 |
| Accessories | Test lead DT4911 ×1 / Holster ×1 / Instruction manual ×1 / LR03 battery ×1 |
| Weight | 190 g (including battery and holster) |
| Other functions | Circuit-breaker false trip prevention / filter function / display hold / relative value display / auto-power save |
| Continuity Check | ON - ≤25 Ω (buzzer sound) / OFF - ≥245 Ω / Response time - ≥0.5 ms |
| Refresh Rate | 5 times/s (Capacitance - 0.05-5 times/s / Frequency - 1-2 times/s) |
Key Features
- The Hioki DT4224 Digital Multimeter Series consists of a diverse array of meters ranging from professional to industrial to pocket meters, delivering a super fast response rate and safety features that take electrical testing to a higher level. The Hioki DT4224 is a pocket-sized digital multimeter featuring an innovative circuit-breaker false trip prevention function to enhance testing safety, capacitance and diode testing functions, ideal for all general electrical jobs.
Product Description
The Hioki DT4200 Digital Multimeter Series consists of a diverse array of meters ranging from professional to industrial to pocket meters, delivering a super-fast response rate and safety features that enhance electrical testing. The Hioki DT4224 is a pocket-sized digital multimeter featuring an innovative circuit-breaker false trip prevention function to enhance testing safety, capacitance and diode testing functions, ideal for all general electrical jobs.
Available on EnvMart, these Multimeters are designed for accurate measurement of voltage, current, and resistance in electrical circuits. Hioki Multimeters offer high precision and reliability, making them essential for electrical testing, diagnostics, and maintenance applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The DC voltage range of the Hioki DT4224 is from 600.0 mV to 600.0 V across 4 ranges, with an accuracy of ±0.5 % reading ±5 digits.
This model can measure AC voltage in the frequency range of 40 Hz to 1 kHz, with an accuracy of ±1.0 % reading ±3 digits.
The capacitance range of the DT4224 is from 1.000 μF to 10.00 mF across 5 ranges, with an accuracy of ±1.9 % reading ±5 digits.
The resistance range for the Hioki DT4224 is from 600.0 Ω to 60.00 MΩ across 6 ranges, with an accuracy of ±0.9 % reading ±5 digits.
It features a main and sub LCD display with 4 digits and a maximum reading of 6000, along with a bar graph for visual representation.
Included accessories are a test lead (DT4911), a holster, an instruction manual, and one LR03 battery.
The Hioki DT4224 operates on one LR03 alkaline battery, providing approximately 35 hours of use with the backlight off.
The weight of this model is 190 g, which includes the battery and holster.
It includes a circuit-breaker false trip prevention function, enhancing safety during electrical testing.
The continuity check is activated when resistance is ≤25 Ω (buzzer sound) and deactivated when resistance is ≥245 Ω, with a response time of ≥0.5 ms.
The refresh rate for standard measurements is 5 times per second, while capacitance measurements refresh at 0.05-5 times per second and frequency measurements at 1-2 times per second.
The Hioki DT4224 is manufactured in Japan.
