Hioki Lux Meter FT3425

Name: Hioki Lux Meter FT3425
Brand: HIOKI
SKU: ADEDU
Price: 818.23 USD
Availability: InStock



SKU ADEDU Category Lux Meter Brand HIOKI Condition New

Specifications

Country of Origin	Japan
Linearity	±2% rdg. (×1.5 for values Greater than 3000 lx)
Sensor	Silicon photo diode
Brand	HIOKI
Power Supply	2× LR6 Alkaline / R6 Manganese / USB power (5VDC)
Dimensions	78×170×39 mm
Battery Life	300 hr (Bluetooth OFF) / 80 hr (Bluetooth ON)
Response time	Auto - ≤5 sec / Manual - ≤2 sec
Model	FT3425
Weight	320 g (including batteries)
Standards	DIN 5032-7 - 1985 Class B / JIS C 1609-1 - 2006 AA Class
Functions	Timer hold / Memory (99 data) / Hold / Auto power-off / Buzzer / Backlight / Zero adjustment
Included Accessories	Batteries / Sensor cap / Carrying case / Strap / USB cable / Software CD / Radio Wave Precautions (FT3425 only)
Range Selection	Auto/Manual
Interfaces	USB 2.0 (FT3424/FT3425) / Bluetooth® 4.0LE (FT3425 only)
Accuracy Conditions	21°C to 27°C / ≤75% RH (non-condensing)
D/A Output	2V/range f.s. / ±1% rdg. ±5mV accuracy

Key Features

Bluetooth® wireless data transfer to smartphone/tablet.
LED/OLED lighting compatible.
DIN 5032-7:1985 Class B and JIS C 1609-1:2006 AA compliant.
Timer hold function for remote measurements.
99-value internal memory, PC transfer for efficiency.
Data transfer to tablets/smartphones via GENNECT Cross app.

Product Description

The FT3425 Lux Meters are supported by the Z5023 Extension Cart, which is built with casters to vastly improve the efficiency of making multi-point light inspections. When conducting final building inspections for proper illuminance, normally two inspectors are needed, and one is often required to stand and crouch repeatedly to capture the correct data. The Z5023 significantly saves both time and effort by enabling a single technician to do the job without the physical burdens.

Available on EnvMart, these Lux Meters are designed for precise measurement of light intensity in environments. Hioki Lux Meters provide high accuracy and reliability, making them essential for lighting testing, environmental assessments, and quality control applications.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The FT3425 Lux Meter is designed for precise measurement of light intensity, but the specific measurement range is not detailed in the provided information.

The FT3425 measures 78×170×39 mm and weighs 320 g, including batteries.

This model can be powered by 2× LR6 Alkaline, R6 Manganese batteries, or via USB power (5VDC).

The battery life is approximately 300 hours with Bluetooth off and 80 hours with Bluetooth on.

It complies with DIN 5032-7:1985 Class B and JIS C 1609-1:2006 AA standards.

It includes a timer hold function, 99-value internal memory, and the ability to transfer data to tablets and smartphones via the GENNECT Cross app.

The accuracy of the FT3425 is ±2% of reading, with a condition of 21°C to 27°C and ≤75% relative humidity (non-condensing).

It utilizes a silicon photo diode as its sensor for measuring light intensity.

Included accessories are batteries, a sensor cap, a carrying case, a strap, a USB cable, a software CD, and radio wave precautions specific to the FT3425.

It features a D/A output of 2V/range full scale with an accuracy of ±1% reading ±5mV.

The response time is auto mode at ≤5 seconds and manual mode at ≤2 seconds.

Yes, it has USB 2.0 and Bluetooth® 4.0LE interfaces for connectivity with other devices.
