Motwane TDR 4000 Cable Fault Pre locator
Specifications
| Country of Origin | India |
|---|---|
| Power Consumption | 36 W max |
| Display | 10.4” / 800x600 TFT / touch-sensitive |
| Brand | Motwane |
| Operating Temperature | -20 ~ +55deg C |
| Dimensions | 366 × 271 × 178mm |
| Connectivity | RS-485 / USB |
| Model | TDR 4000 |
| Control | Touchscreen and control knob |
| Operating Mode | TDR / ARC / ICE / Decay |
| Sampling rate | 400MHz |
| Internal Data Storage | 4 Gb (not less than 1000 reflectograms with data) |
| Pulse Width | 10ns – 100 000ns |
| Pulse Amplitude | 45V |
| Distance measurement ranges m@v/2 equal to 100m/μs | 60 / 120 / 250 / 500 / 1000 / 2000 / 5000 / 10000 / 20000 / 50000 / 120000 |
| Resolution (− 0.5 @ v/2) − 0.4 @ v/2 | 100 m/μs Less than brGreater than 80 m/μs |
| Gain | -33 – 104dB |
| Output impedance (10 Ohm steps) | 10 – 500 Ohm |
| Propagation velocity (v/2) | 50.0 – 150.0m/μs |
| Averaging reflectograms number | 64 max |
| Time domain accuracy | % of FS 0.2 |
| Propagation velocity (V/2) resolution | 0.1 m/us |
| Internal battery | 12 V (8 hours of operating when fully charged) |
| External power adaptor | Input 230V 50 Hz Less than brGreater than Output 24 V DC |
| Net Weight (with internal battery) | 8.0 kg |
Key Features
- Determining the distance to a fault or discontinuity in symmetric and asymmetric cables using a location (time domain reflection) method.
- Measuring the length of a cable (including those wound on a drum) or distance to a fault or a short circuit.
- internally or using a supplied PC software.
- As part of a Cable Test Van,determining the distance to a fault or discontinuity in cables with length of up to 100 km for all possible fault types without the need of preliminary full cable sheath burning.
Product Description
TDR 4000 provides you with 10.4-inch bright high-contrast TFT display with touchscreen. The 800*600 pixels resolution makes the picture sharp. The touchscreen allows an operator navigate through the menu fast and easy. An alternative way of navigation is included. It is provided with a control knob.
TDR 4000 integrates a multiple ways of fault prelocation. It can be used either as a standalone device in TDR mode or in a conjunction with HV-module. (e.g. Cable test van or Surge wave generator), working in arc reflection (ARC), impulse current (ICE) and decay modes. A high-capacity internal battery allows working up to 8 hours.
TDR 4000 has both RS-485 and USB interfaces. The package content includes software for PC (optional), which allows working with saved reflectograms. The firmware is easily updated through USB interface by inserting a flash drive.
Application
Battery powered Digital Impulse Reflectometer (TDR) TDR 4000 designed for determining the distance to a fault in communication and power cables.
Available on EnvMart, these Cable Trackers are designed for precise wire tracing and continuity testing in electrical installations. Motwane Cable Trackers are known for their accuracy and efficiency, making them essential tools for electricians, telecom technicians, and network engineers.
