TE Connectivity PCB Mount Toggle Switch On-On SPDT Through Hole Terminal 28 V dc 115 V ac 1825136-9

TE Connectivity 1825136-9 Toggle Switch is a high-quality, PCB mount switch with On-On SPDT operation, designed for versatile electrical and automation applications. It operates at 28 V dc and 115 V ac, making it suitable for a wide range of low-voltage control circuits and machinery. The through hole terminal enables easy and secure mounting on printed circuit boards.

This toggle switch features a robust actuator made from phenolic material measuring 18.03 mm in length, with a stainless steel frame and brass tin plated solder support, ensuring long-lasting mechanical stability. The switch is crafted with epoxy sealed terminals providing protection against contaminants.

Rated IP67, it offers excellent resistance to dust ingress and water, ideal for industrial environments requiring high reliability. It supports a contact current of 5A and a temperature operating range from -30°C to 85°C, allowing it to perform consistently under varying temperature conditions.

The SPDT On-On configuration allows control of two output circuits with a single input, commonly used for circuit selection or polarity reversal applications. The toggle switch also utilizes break-before-make contact timing to prevent short circuits during switching.

This product is RoHS compliant, ensuring it meets environmental safety standards. Typical industrial use cases include automation controls, manufacturing equipment, and electrical appliances where reliable manual switching is required.

The switch supports a contact configuration of SPDT (Single Pole Double Throw). Designed for a maximum switch contact current of 5A. The actuator has a length of 18.03mm and is made from durable phenolic material. Rated for contact voltages of 28 V dc and 115 V ac for diverse applications.

The switch features IP67 protection rating ensuring dust and water resistance. Operation temperature ranges from -30°C to 85°C, suitable for varied environments. The switch uses break before make contact timing and epoxy sealed terminals for enhanced durability.

Constructed with a stainless steel frame and brass tin plated solder support for robustness. This non-illuminated toggle switch is RoHS compliant and ideal for automation and electrical systems. For more high-quality Toggle Switches and electrical components, explore the Electronics & Electricals category on EnvMart.
