Omron Subminiature Pin Plunger Micro Switch, Through Hole Terminal, 5A, 250V AC, SPDT, IP40 SS-5-FD

Free Delivery in India | Lowest Global Shipping Charges

Omron Subminiature Pin Plunger Micro Switch, Through Hole Terminal, 5A, 250V AC, SPDT, IP40 SS-5-FD

Name: Omron Subminiature Pin Plunger Micro Switch, Through Hole Terminal, 5A, 250V AC, SPDT, IP40 SS-5-FD
Brand: Omron
SKU: 425337
Price: 1.94 USD
Availability: InStock



Category Micro Switch Brand Omron Condition New

Specifications

Country of Origin	Indonesia
Brand	Omron
Model	SS-5-FD
IP Rating	IP40
Series	SS
Maximum Operating Temperature	85°C
Contact Configuration	SPDT
Actuator Type	Pin Plunger
Minimum Operating Temperature	-25°C
Terminal type	Through Hole
Standards/Approvals	RoHS
Switch Contact Current	5A
Operating Force	0.49N
Mechanical Life	30000000Operations
Contact AC Voltage	250V ac
Microswitch Type	Subminiature

Key Features

The switch features a pin plunger actuator for precise mechanical operation.
Through hole terminal type suitable for PCB mounting and soldering applications.
Its rated current is 5 amperes ensuring suitability for moderate load electrical control.
Designed with SPDT (Single Pole Double Throw) contact configuration for versatile circuit switching.
IP40-rated housing offers protection against solid foreign objects exceeding 1 mm in size.
Operating force of 0.49N allows for low actuation energy requirements.
Operating temperature range from -25°C to 85°C suits diverse environments.
The switch is of subminiature microswitch type with a mechanical life expectancy of 30 million operations for extended durability.

Product Description

Omron SS-5-FD is a subminiature basic micro switch featuring a pin plunger actuator and through hole terminals, rated for electrical switching up to 5 amperes at 250 volts AC.

This micro switch is designed for applications requiring precise and reliable actuation with a single pole double throw (SPDT) contact configuration. The pin plunger actuator ensures consistent activation with an operating force of 0.49N, suitable for delicate mechanisms.

The device is housed to an IP40 ingress protection standard, safeguarding it against solid particles larger than 1 millimeter, making it suitable for indoor industrial and electrical control environments.

Engineered for robustness, it offers a long mechanical life of 30 million operations, enabling extended use in manufacturing, automation, HVAC systems, and various industrial control systems requiring frequent switching cycles.

Operating temperature ranges from -25°C to 85°C ensure functionality under diverse ambient conditions. Compliance with RoHS directives confirms environmentally responsible manufacturing.

Manufactured in Indonesia, this Omron SS series switch is ideal for electrical equipment, automation systems, and machinery control panels demanding compact and dependable microswitch solutions.

The switch features a pin plunger actuator for precise mechanical operation. Through hole terminal type suitable for PCB mounting and soldering applications. Rated current of 5 amperes ensuring suitability for moderate load electrical control.

SPDT contact configuration for versatile circuit switching. IP40-rated housing offers protection against solid foreign objects exceeding 1 mm in size. Operating force of 0.49N allows for low actuation energy requirements.

Operating temperature range from -25°C to 85°C suits diverse environments. Subminiature microswitch type with mechanical life expectancy of 30 million operations. RoHS compliant ensuring adherence to environmental standards.

Manufactured in Indonesia maintaining quality production standards. Explore more Omron Micro Switches and related electrical components on EnvMart for reliable industrial automation products.
