Winbond NOR 128 MB SPI Flash Memory 8-Pin SOIC W25Q128JVSIQ/TUBE

Winbond W25Q128JVSIQ/TUBE is a high-performance NOR flash memory chip delivering 128MB storage capacity configured as 16 million words by 8 bits organisation. This 8-pin SOIC package memory operates using a Serial Peripheral Interface (SPI) suitable for a wide range of electronic applications including embedded systems, industrial control, consumer electronics, and data storage modules.

The device supports Single, Dual, and Quad SPI modes, enabling high-throughput read speeds up to a maximum clock frequency of 133 MHz. With a power supply voltage range of 2.7 to 3.6 volts, it ensures efficient power management and compatibility with standard logic voltages.

It features uniform 4KB erasable sectors along with larger 32KB or 64KB block erase options, optimizing memory management and data updating processes. The maximum random access time of 6 nanoseconds ensures rapid data retrieval for real-time processing demands. The compact 5.38mm x 4mm x 1.91mm SOIC package makes it highly suitable for automated surface mount technology assembly.

Designed to operate in harsh temperature environments from -40°C to 85°C, the device is suitable for industrial and automotive electronics. The supply current is optimized at 25 mA, balancing performance and power consumption effectively. As a part of the W25Q128JV series, this memory device does not conform to automotive-specific standards but is widely used in commercial, industrial, and consumer sectors.

The product is manufactured in Taiwan, Province Of China, adhering to quality assurance standards and RoHS compliance. It is ideal for applications requiring reliable non-volatile memory with fast access times and flexible SPI interface operation modes.

128M-bit serial flash memory with uniform 4KB sectors and dual/quad SPI modes. Supports Single, Dual, Quad SPI operations for scalability in communication speeds. Operating voltage between 2.7V and 3.6V suitable for low-power systems.

Small 8-pin SOIC package allowing dense PCB layouts. Wide operating temperature range from -40°C to 85°C for industrial applications. Compact dimensions of 5.38mm L x 4mm W x 1.91mm H ensuring space-saving implementations.

Typical page program time of 0.7 ms with 256-byte page size supporting fast programming. Continuous read operation with wrap support enhances efficiency in sequential data processing. Ideal for embedded industrial, automotive, and consumer electronics requiring reliable Flash Memory.
