Samtec Right Angle Surface Mount Female 1-Port Micro USB Type AB Connector USB 2.0 30V IP68 MUSB-05-F-AB-SM-A

Free Delivery in India | Lowest Global Shipping Charges

Samtec Right Angle Surface Mount Female 1-Port Micro USB Type AB Connector USB 2.0 30V IP68 MUSB-05-F-AB-SM-A

Name: Samtec Right Angle Surface Mount Female 1-Port Micro USB Type AB Connector USB 2.0 30V IP68 MUSB-05-F-AB-SM-A
Brand: Samtec
SKU: 419466
Price: 1.48 USD
Availability: InStock



Category USB Connector Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	30V
Brand	Samtec
Orientation	Right Angle
Model	MUSB-05-F-AB-SM-A
IP Rating	IP68
Mount Type	Surface
Contact Material	Phosphor Bronze
Series	MUSB
Number Of Ports	1
Termination Type	Solder
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-50°C
Interfaces	USB 2
USB Type	Micro USB Type AB
Connector Gender	Female
USB Specification	USB 2.0

Key Features

Offers a durable right angle surface mount design for secure PCB integration.
Compatible with Micro USB Type AB interface supporting USB 2.0 connectivity.
Rated for operation at voltages up to 30V with IP68 ingress protection for robust environmental resistance.
Constructed with phosphor bronze contacts ensuring reliable electrical performance.
Designed to operate within temperature ranges of -50°C to 85°C for industrial applications.
Solder termination type for stable mounting on surface PCB pads.
Available in standard series MUSB with options for cost-saving flash gold plating.
Suitable for use in electronic components, power, and connectors sectors.

Product Description

Samtec MUSB-05-F-AB-SM-A is a right angle, surface mount female USB connector featuring a single port with Micro USB Type AB interface, compliant with USB 2.0 standards. Its robust IP68 rating ensures dust tight and water immersion protection, making it highly reliable for demanding industrial and electronic applications.

The connector supports a voltage rating of 30V and operates effectively in a wide temperature range from -50°C to 85°C. The termination type is solder, designed for secure attachment to PCB surface pads, ensuring mechanical stability and optimal electrical connection.

Manufactured using phosphor bronze contact material, this component guarantees excellent conductivity and durability. It belongs to the MUSB series and offers options for standard or high-retention contact configurations, including cost-effective flash gold plating to enhance corrosion resistance and longevity.

Ideal for integration in various electronics, power supply, and connector applications, this connector facilitates seamless micro USB interfacing in compact and robust form factors.

Durable right angle surface mount design for stable PCB integration. Compatible with Micro USB Type AB interface supporting USB 2.0. Rated for voltages up to 30V with IP68 ingress protection. Phosphor bronze contacts for reliable electrical performance.

Operating temperature range of -50°C to 85°C. Solder termination for secure mounting. Available in MUSB series with options for flash gold plating. Suitable for demanding industrial and electronic components applications.

This Samtec USB Connector is an excellent choice for manufacturers and engineers seeking a robust, high-quality USB interface component suitable for harsh environments. Explore more in our Electronics & Electricals category to find compatible connectors and components.
