KEMET R76_125C Film Capacitor, 27 nF, ±5% Tolerance, 2 kV DC 700 V AC, Through Hole Mount, Series R76UN227050H4J

KEMET R76UN227050H4J Film Capacitor is a high-quality component constructed from polypropylene film with double metallized polyester film electrodes, designed for reliable performance in demanding industrial and electronic applications. This through hole mount capacitor offers a capacitance of 27 nF with a tolerance of ±5%, rated for 2 kV DC voltage and 700 V AC voltage, ensuring stable operation in high voltage environments.

The capacitor features radial tinned wire leads, welded electrically to the metal layer ends of the capacitor winding, encapsulated within a thermosetting resin plastic case that is solvent resistant and self-extinguishing, providing enhanced durability and safety. The operating temperature range of -55°C to 125°C makes it suitable for harsh industrial conditions.

This capacitor complies with international IEC 60286-2 standards and RoHS directives and meets the automotive grade AEC-Q200 standard, highlighting its robustness and reliability in automotive and industrial use. With a lead pitch of 22.5 mm, lead length of 25 mm, lead diameter of 0.8 mm, and 2 pins, it is ideal for through hole soldering on printed circuit boards.

Applications include use in resonant circuits, high frequency and high current environments, snubber circuits, and commutation circuits for silicon-controlled rectifiers (SCR), insulated gate bipolar transistors (IGBT), and silicon carbide (SiC) MOSFETs. It supports high voltage and current loads especially in circuits requiring operation under elevated ambient temperatures.

Polypropylene film and metallized polyester electrodes construction. Encapsulated in solvent resistant, self-extinguishing plastic case. Suitable for temperatures ranging from -55°C to 125°C. International standard compliance IEC 60286-2 and RoHS certified.

Automotive AEC-Q200 certification for automotive applications. Through hole mounting with radial tinned wire leads. Capacitance tolerance of ±5% ensures precise capacitance value. Applications in resonant, snubber, and commutation circuits.

This capacitor is an excellent choice for industrial, automotive, and electronic manufacturing sectors requiring reliable and high-performance film capacitors. Explore more Film Capacitors and electronic components on EnvMart to find suitable parts for your projects and manufacturing line.
