MEAN WELL SD-100 DC/DC Converter 48V DC Output, 21A Output Current, 72-96V DC Input, 1008W Power Surface Mount SD-1000H-48
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters MEAN WELL SD-100 DC/DC Converter, 48V dc/ 21 A, 96 |
| Brand | MEAN WELL |
| Efficiency | 92% |
| Length | 295mm |
| Model | SD-1000H-48 |
| Depth | 41mm |
| Gross Weight | 1.94kg |
| Width | 41mm |
| Mount Type | Surface |
| Series | SD-100 |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -20°C |
| MTBF | 898200h |
| Number of outputs | 1 |
| Ripple and Noise | 150mV Pk-Pk |
| Maximum Output Power | 1008W |
| Maximum Input Voltage | 96V dc |
| Standards/Approvals | ENV 50204, EN 55022Class B, EN 61000-4-2 |
| Minimum Input Voltage | 72V |
| Output Voltage 1 | 48V dc |
| Output Current 1 | 21A |
| Output Voltage Adjustment Range | 60 V |
| Isolation Voltage | 2kV ac |
| Ultra-wide 4 | 1 input voltage range |
Key Features
- High efficiency up to 92 percent ensures low power loss during operation.
- Surface mount type with compact dimensions of 295mm length, 41mm width, and 41mm depth.
- Operating temperature range from -20° to 60°C suitable for demanding environments.
- Built-in protections including short circuit, overload, over-voltage and over-temperature ensure reliable performance.
- Isolation voltage of 2kV AC provides electrical safety and noise immunity.
- Low ripple and noise of 150mV peak-to-peak enhances output quality for sensitive electronics.
- Remote ON/OFF control and remote sensing features enhance system integration and control.
- LED power-on indicator offers visual operation status monitoring.
Product Description
MEAN WELL SD-1000H-48 is a single output regulated isolated DC-DC converter delivering 48V DC output at 21A current with a maximum output power of 1008W. It supports a wide input voltage range from 72V to 96V DC, making it suitable for various industrial power supply applications.
The device features a compact 1U low profile surface mount package measuring 295mm in length and 41mm in both width and depth. It offers high power density of approximately 10.7W/in³ and excellent efficiency rated at 92%, reducing energy loss and heat generation.
Designed for harsh industrial environments, it operates reliably in a temperature range from -20°C to 60°C and includes comprehensive protective functions such as short circuit, overload, over-voltage, and over-temperature protection. The 2kV AC input/output isolation ensures electrical safety and minimizes electrical noise interference.
Additional functional advantages include remote ON/OFF control, remote sensing for voltage compensation, and dual cooling fans with speed control for effective thermal management. The LED power indicator provides easy visual confirmation of operational status.
With a high Mean Time Between Failures (MTBF) of 898,200 hours, and compliance with EN 55022 Class B EMC standards and IEC 60950-1 safety standards, this converter is ideal for industrial automation, telecommunications, and other critical power applications.
High efficiency and power density with reliable operation. Wide 4:1 input voltage range for flexible use. Robust protection features ensure safe and stable performance. Compact surface mount form factor for easy installation.
Designed for industrial environmental conditions and standards compliance. Remote control and monitoring capabilities for integration. Effective cooling ensures longevity and reliability under load. Suitable for use in industrial, laboratory, manufacturing, and power supply systems.
Explore MEAN WELL DC/DC Converter category on EnvMart for compatible industrial power solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MEAN WELL SD-1000H-48 provides an output voltage of 48V DC and an output current of 21A.
It supports a wide input voltage range from 72V to 96V DC.
The maximum output power of this converter is 1008W.
This unit has compact dimensions of 295mm in length, 41mm in width, and 41mm in depth.
It has an efficiency rating of 92%, ensuring low power loss during operation.
The operating temperature range is from -20°C to 60°C, suitable for demanding environments.
It includes built-in protections such as short circuit, overload, over-voltage, and over-temperature protection.
The isolation voltage is 2kV AC, providing electrical safety and noise immunity.
The gross weight of this model is 1.94kg.
The output ripple and noise is specified at 150mV peak-to-peak.
Yes, it features remote ON/OFF control and remote sensing capabilities for enhanced system integration.
It complies with EN 55022 Class B EMC standards and IEC 60950-1 safety standards.
