MEAN WELL DDR-15L-15 DC/DC Converter, 24V Output, 18-75V DC Input, 15W Power, DIN Rail Mount, 4-Pin, -40°C to 85°C DDR-15L-15

MEAN WELL DDR-15L-15 DC/DC Converter is a slim and ultra-wide input range power supply unit designed for industrial control, factory automation, telecommunications, and data communication systems. It delivers a stable 24V output with up to 15W of power, powered from a DC input voltage ranging from 18V to 75V, making it versatile for demanding applications.

The compact DIN rail mount design allows efficient and easy integration into electrical panels and control cabinets. This converter features wide operating temperature capabilities from -40°C to 85°C, ensuring reliable performance under harsh industrial environments. With a 4-pin interface, it supports secure connections and installation.

Outstanding electrical characteristics include low ripple noise of 100mV peak to peak, output voltage adjustable within 21.6 to 28V, and a robust output current of 4.5A. Efficiency reaches 87%, minimizing energy loss and heat generation. It offers essential protections such as input under-voltage lockout and reverse polarity protection to safeguard your system.

The product complies with key standards and approvals including EN55032, IEC 62368-1 (LVD), and UL508 design guidelines, further ensuring safety and electromagnetic compatibility in industrial settings.

Its reinforced 4KVdc input/output isolation provides protection against electrical faults and noise, making it suitable for sensitive electronic equipment. The mean time between failures (MTBF) is rated at 907,000 hours, reflecting excellent reliability for long-term usage.

This DC/DC converter is ideal for a range of industrial applications such as electro-mechanical systems, wireless networks, factory automation, telecom infrastructures, and other demanding environments requiring dependable DC voltage conversion.

Supports a maximum input voltage of 75V DC and a minimum input voltage of 18V DC. Features DIN rail mounting for easy installation. Offers an output current of 4.5A and adjustable output voltage between 21.6 to 28 V. Designed to operate reliably from -40°C to 85°C ambient temperature.

Ensures low ripple and noise at 100mV peak to peak for stable output. Includes 4 pins and has a compact form factor with dimensions 54.5mm depth, 17.5mm width, and 9mm length. High efficiency of 87% suitable for industrial control systems and automation.

Built-in protections such as input reverse polarity and input under-voltage protection. Reinforced 4KVdc input/output isolation enhances safety and reliability. Explore more DC/DC Converters and power supplies at EnvMart for your industrial and commercial electrical equipment needs.
