KEMET R47 Film Capacitor X2, ±10 % Tolerance, 680 nF, 1 kV DC, 440 V AC, Through Hole Mount R474R36805001K

KEMET R474R36805001K Film Capacitor X2 is a precision passive electronic component offering a capacitance of 680 nF with ±10% tolerance. It is designed for EMI suppression and filtering in AC and DC circuits. Rated for 1 kV DC and 440 V AC operation, it is well suited for demanding automotive and industrial environments requiring robust insulation and electrical performance.

This capacitor features through hole mounting with radial terminal types and a lead pitch of 27.5 mm, providing secure and easy PCB assembly. Its leads have a diameter of 0.8 mm and length of 25 mm, facilitating reliable solder connections. The product operates across a temperature range of -40°C to +110°C, making it ideal for applications exposed to varying thermal conditions.

The capacitor is constructed from metallized polypropylene film encapsulated in a self-extinguishing resin box, which enhances safety by preventing fire spread. It possesses self-healing properties that restore dielectric after minor faults, thus extending product life and reliability. It is compliant with the automotive quality standard AEC-Q200 and certified against CAN, CSA, EN, IEC, and UL standards, ensuring global industrial acceptance.

With a dissipation factor of just 0.1%, this capacitor operates with minimal energy loss, improving system efficiency. The climatic category rating of 40/110/56 validates its endurance in diverse environmental conditions. Additionally, the product’s suppression class X2 rating ensures effective electromagnetic interference suppression, critical for sensitive electronics.

Capacitance of 680 nF with ±10% tolerance ensures precise filtering performance. Rated DC voltage of 1 kV and AC voltage of 440 V provide high-voltage compatibility. Through hole mount and radial terminals enable robust PCB installation.

Lead pitch of 27.5 mm and lead length of 25 mm accommodate standard assembly requirements. Operating temperature range from -40°C to +110°C suits demanding environments. Meets automotive AEC-Q200 standard for quality and performance assurance.

Safety certified under CAN, CSA, EN, IEC, and UL standards. Constructed with metallized polypropylene film and self-extinguishing resin enclosure. Self-healing dielectric properties enhance reliability and lifespan. Low dissipation factor of 0.1% reduces energy losses.

This KEMET film capacitor is ideal for industrial electronics, automotive EMI suppression, power supplies, instrumentation, and other applications requiring reliable high voltage AC and DC capacitors. Available in a bag package, it ensures protection during transportation and storage. Explore EnvMart’s wide range of Film Capacitors for your electronic design needs.
