KEMET R47 X2 Film Capacitor X2, ±10 %, 220 nF, 1 kV DC, 440 V AC, Through Hole R474N32205001K

KEMET R474N32205001K Film Capacitor is a high-quality electronic component designed for EMI suppression and timing circuits, offering a capacitance of 220 nF with ±10% tolerance. This through-hole capacitor supports a rated DC voltage of 1 kV and AC voltage of 440 V, making it suitable for industrial, automotive, and power electronics applications.

The capacitor features a metallized polypropylene film encapsulated with a self-extinguishing resin body, ensuring enhanced durability and safety compliance. Its operating temperature range from -40°C to 110°C accommodates harsh environmental conditions typically encountered in manufacturing and HVAC systems.

With a lead pitch of 22.5 mm, lead length of 25 mm, and radial terminal type, it is designed for secure PCB mounting. The component meets automotive standard AEC-Q200 and holds certifications such as CAN, CSA, EN, IEC, and UL, underlining its reliability and quality assurance for industrial use.

Additional physical specifications include a compact size measuring 26.5 mm in length, 20 mm in height, and 11 mm in width, complemented by a low dissipation factor of 0.1%, which minimizes power loss. The suppression class X2 rating confirms its suitability for EMI noise reduction in sensitive electrical circuits.

Capacitance value is precisely 220 nF with ±10 % tolerance. Rated for 1 kV direct current and 440 V alternating current applications. Designed with a through-hole radial terminal mount for reliable PCB installation. Constructed from metallized polypropylene film encapsulated in self-extinguishing resin for enhanced safety.

Supports an operating temperature range from -40°C to 110°C suitable for varied environments. Lead pitch measures 22.5 mm with a lead length of 25 mm and lead diameter of 0.8 mm. Complies with automotive standard AEC-Q200 and multiple certifications including CAN, CSA, EN, IEC, and UL.

Suppression class is X2 for EMI noise suppression applications. Compact dimensions of 26.5 mm length, 20 mm height, and 11 mm width optimize space usage. Features low dissipation factor of 0.1 % ensuring minimal energy loss during operation.

This capacitor is ideal for use in industrial manufacturing, automotive electronics, laboratory instruments, power supplies, and HVAC systems requiring high reliability and precision.
