MEAN WELL DC/DC Converter, 24V DC Output, 72V DC Maximum Input, 1.25A Output Current, 30W Power, Chassis Mount RSD-30L-24

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL DC/DC Converter, 24V DC Output, 72V DC Maximum Input, 1.25A Output Current, 30W Power, Chassis Mount RSD-30L-24

Name: MEAN WELL DC/DC Converter, 24V DC Output, 72V DC Maximum Input, 1.25A Output Current, 30W Power, Chassis Mount RSD-30L-24
Brand: MEAN WELL
SKU: 414251
Price: 58.37 USD
Availability: InStock



Category DC/DC Converter Brand MEAN WELL Condition New

Specifications

Country of Origin	China
Voltage	Converters / DC-DC Converters MEAN WELL RSD-30 DC/DC Converter, 24V dc/, 72V dc
Brand	MEAN WELL
Efficiency	91%
Length	113mm
Model	RSD-30L-24
Depth	25mm
Gross Weight	250g
Width	60mm
Mount Type	Chassis Mount
Series	RSD-30
Minimum Operating Temperature	70°C
MTBF	396900h
Number of outputs	1
Ripple and Noise	50mV Pk-Pk
Maximum Output Power	30W
Maximum Input Voltage	72V dc
Standards/Approvals	CE
Minimum Input Voltage	18V
Output Voltage 1	24V dc
Output Current 1	1.25A
Isolation Voltage	4kV dc
Input Ratio	1:6
Input Ratio1	6

Key Features

Provides stable 24V DC output voltage with 30W maximum power capacity.
Supports wide input voltage range from 18V minimum to 72V maximum for versatility.
Compact chassis mount design with dimensions 113mm x 60mm x 25mm effectively saves space.
Features 4000V DC isolation voltage ensuring safety and noise reduction.
Offers high efficiency of 91% with low ripple and noise of 50mV Pk-Pk for reliable operation.
Operates within temperature range of -40°C to +70°C for robust industrial use.
Includes built-in constant current limiting circuit and overload protection for safe performance.
Complies with CE standards and railway-grade certifications EN50155 & IEC60571.

Product Description

MEAN WELL RSD-30L-24 DC/DC Converter is a highly reliable power conversion module designed for industrial and transportation applications requiring stable 24V DC output from a wide 18V to 72V DC input range. It supports a maximum output power of 30W with an output current of 1.25A, suitable for powering electronic circuits, control systems, and railway equipment.

This chassis mount converter has a compact form factor with dimensions of 113mm length, 60mm width, and 25mm depth, making it ideal for space-constrained environments. Its 4000V DC isolation voltage offers enhanced electrical isolation and minimizes noise interference.

The product achieves high efficiency of 91%, significantly reducing energy loss and heat generation. The low ripple and noise (50mV Pk-Pk) ensures clean power delivery to sensitive electronics.

Designed to operate reliably in extreme conditions, it supports continuous operation in a wide ambient temperature range from -40 to +70°C. Safety features include built-in constant current limiting and overload protection that shuts down the output voltage under excessive load and recovers upon restart.

Compliance with CE standards and railway certifications EN50155 and IEC60571 attests to its quality and suitability for demanding industrial scenarios including transportation systems, manufacturing plants, and automation setups.

Provides regulated 24V DC output with 30W capacity and 1.25A current. Wide input range from 18V to 72V DC supports various power sources. Compact chassis mount enclosure for easy integration. High isolation voltage of 4kV DC for safety.

Low ripple & noise with high efficiency of 91%. Wide operating temperature range (-40°C to +70°C). Built-in safety features including current limiting and overload protection. Complies with CE, EN50155 & IEC60571 railway standards.

Weighs 250g suitable for board-level power distribution.

This converter is widely used in industrial power supplies, transportation systems, automation control, and other applications requiring reliable DC voltage conversion. For more precision and reliability in power conversion, browse related DC/DC Converters in our Electronics & Electricals category at EnvMart.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This model provides a regulated output voltage of 24V DC with a maximum output current of 1.25A.

The maximum input voltage for this converter is 72V DC, allowing it to support a wide range of input sources.

It achieves a high efficiency rating of 91%, which helps to minimize energy loss during operation.

The dimensions of this unit are 113mm in length, 60mm in width, and 25mm in depth, making it compact for installation.

This DC/DC converter features an isolation voltage of 4000V DC, ensuring enhanced electrical isolation and safety.

It operates reliably within a temperature range of -40°C to +70°C, suitable for various industrial environments.

Yes, it includes a built-in constant current limiting circuit and overload protection to ensure safe performance.

The ripple and noise level is specified at 50mV Pk-Pk, which ensures clean power delivery to sensitive electronics.

This model complies with CE standards and railway-grade certifications EN50155 and IEC60571, indicating its suitability for demanding applications.

The gross weight of this unit is 250g, making it manageable for installation in various applications.

It is widely used in industrial power supplies, transportation systems, automation control, and other applications requiring reliable DC voltage conversion.

The minimum input voltage required for operation is 18V DC, which allows for flexibility in power source selection.
